Application Scenario:
Loading Cargo
- Product Details
- {{item.text}}
Quick Details
-
Dimension:
-
2730X1460X1885 mm
-
Place of Origin:
-
Jiangsu, China
-
Engine:
-
4 Stroke
-
Brake:
-
Front Disc Brake
-
MAX SPEED:
-
60-80km/h
-
Transmission:
-
CVT L-H-N-R
Quick Details
-
Displacement:
-
>300cc
-
Brand Name:
-
LINHAI
-
Tire Size:
-
AT 25X10-12
-
Dimension:
-
2730X1460X1885 mm
-
Place of Origin:
-
Jiangsu, China
-
Engine:
-
4 Stroke
-
Brake:
-
Front Disc Brake
-
MAX SPEED:
-
60-80km/h
-
Transmission:
-
CVT L-H-N-R
Product Specification
|
Size: L×W×H
|
2730×1460×1885 mm
|
|
Wheelbase
|
1855 mm
|
|
Ground clearance
|
280 mm
|
|
Dry weight
|
525 kg
|
|
Loading capacity
|
300 kg
|
|
Fuel Tank Capacity
|
26 L
|
|
Max speed
|
>70 km/h
|
|
Specification of tire
|
Front: AT 25×8-12
Rear: AT 25×10-12
|
|
Brake control model
|
Front: Foot brake
Rear: Foot brake
|
|
Brake system model
|
Front: Disk brake
Rear: Disk brake
|
|
Suspension type
|
Front: McPherson
independent suspension
Rear: Twin-A arms
independent suspension
|
|
Engine type
|
LH188MR-A
|
|
Engine model
|
Single cylinder, 4 stroke, water cooled, 4 valve
|
|
Cylinder dimension
|
493 cc
|
|
Bore and Stroke
|
87.5 × 82 mm
|
|
Rated power
|
24/6500 (kw/r/min)
|
|
Max torque
|
38.8/5500 (Nm/r/min)
|
|
Compression Ratio
|
10.2:1
|
|
Fuel system
|
EFI
|
|
Start type
|
Electric starting
|
|
Transmission
|
Automatic L-H-N-R-P
|
Details Images
Factory Photo
Product Application
Application Scenario: Off Road
Application Scenario: P
arent-child Interaction
Product Packaging
|
Length
|
2300 mm
|
|
Width
|
1480 mm
|
|
Height
|
1220 mm
|
|
G.W.
|
578 kg
|
|
N.W.
|
538 kg
|
|
Vol.
|
4.15 m³
|
|
40'HQ
|
16 pcs
|
FAQ
1. Q: Can I get some samples?
A: We are honored to sell samples to you for quality check.
2. Q: Do you have the products in stock?
A: According to the actual inventory.
3. Q: What’s the delivery time?
A: It usually takes about 60 working days to produce an order. But the
A: We are honored to sell samples to you for quality check.
2. Q: Do you have the products in stock?
A: According to the actual inventory.
3. Q: What’s the delivery time?
A: It usually takes about 60 working days to produce an order. But the
exact delivery time depends on different situation.
4. Q: Can I mix different models in one container?
A: Yes, different models can be mixed in one container.
5. Q:What's your warranty terms?
A: We offer 1 year warranty. Please contact with us for details.
4. Q: Can I mix different models in one container?
A: Yes, different models can be mixed in one container.
5. Q:What's your warranty terms?
A: We offer 1 year warranty. Please contact with us for details.
