Quick Details
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CE, ISO9001,ROHS, CE RoHS
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SNADI
-
Model Number:
-
300W-5KW Solar Generator
-
Load Power (W):
-
600W, 1200W, 2200W, 3800W, 5000W
-
Output Voltage (V):
-
110V/220V
-
Output Frequency:
-
50/60Hz
-
Work Time (h):
-
24 hours
-
Specification:
-
Normal
-
Product name:
-
Home portable solar power generator
-
Solar panel:
-
Monocrystalline Silicon
-
Type:
-
Off-grid System AC
-
Battery capacity:
-
55AH/100AH/200AH
-
AC output:
-
110V/120V
-
Output wave:
-
Pure Shine Wave
-
Use:
-
Domestic power supply
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon, Polycrystalline Silicon
-
Battery Type:
-
Lead-Acid, Lithium Ion, LiFePO4
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CE, ISO9001,ROHS, CE RoHS
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SNADI
-
Model Number:
-
300W-5KW Solar Generator
-
Load Power (W):
-
600W, 1200W, 2200W, 3800W, 5000W
-
Output Voltage (V):
-
110V/220V
-
Output Frequency:
-
50/60Hz
-
Work Time (h):
-
24 hours
-
Specification:
-
Normal
-
Product name:
-
Home portable solar power generator
-
Solar panel:
-
Monocrystalline Silicon
-
Type:
-
Off-grid System AC
-
Battery capacity:
-
55AH/100AH/200AH
-
AC output:
-
110V/120V
-
Output wave:
-
Pure Shine Wave
-
Use:
-
Domestic power supply
* Do you need a sample now?
Contact us !
|
Model: ALS
|
600W/12V
|
1200W
|
2200W
|
|
||||
|
Inverter
|
|
|
|
|
||||
|
Battery voltage
|
50ah/12V.8v
|
50ah/25.6v
|
100ah/25.6v
|
|
||||
|
Rated power
|
600W
|
1200w
|
2200w
|
|
||||
|
Output voltage
|
110/220VAC
|
|
|
|
||||
|
Output frenquency
|
50/60HZ
|
|
|
|
||||
|
Output waveform
|
Pure sine wave
|
|
|
|
||||
|
Charge by a mains supply
|
|
|
|
|
||||
|
Input voltage
|
72-138VAC/145-275VAC
|
|
85-138/170-275VAC
|
|
||||
|
input frequency
|
45-65Hz
|
|
|
|
||||
|
MPPT charge
|
|
|
|
|
||||
|
Maximum photovoltaic voltage
|
≤100V
|
≤100V
|
|
|
||||
|
PV input range voltage
|
18-100v
|
35-100v
|
|
|
||||
|
Rated charge current
|
30A
|
30A
|
|
|
||||
|
Maximum power
|
420Wp
|
840Wp
|
|
|
||||
|
MPPT efficiency
|
≥97%
|
|
|
|
||||
|
DC output
|
|
|
|
|
||||
|
Voltage of high voltage protection
|
16V
|
32V
|
|
|
||||
|
Voltage of high voltage recovery
|
14.5V
|
29v
|
|
|
||||
|
Voltage of low voltage recovery
|
13v
|
26v
|
|
|
||||
|
Voltage of low voltage protection
|
2 units/MAX 2A
|
|
|
|
||||
|
5VDC USB output port
|
2 DC ports/MAX2A
|
|
|
|
||||
|
other
|
|
|
|
|
||||
|
heat dissipation/Cooling
|
Temperature control by intelligent exhaust fan
|
|
|
|
||||
|
Ambient temperature for operation
|
-25+50℃
|
|
|
|
||||
|
Ambient temperature for storage
|
-25+55℃
|
|
|
|
||||
|
operation/storage conditionas
|
0-90%( no condensation)
|
|
|
|
||||
|
External dimensions: D*W*H(mm)
|
460*182*397
|
485*202*406
|
540*229*444
|
|
||||
|
Packing dimensions: D*W*H(mm)
|
540*277*470
|
565*298*477
|
620*325*515mm
|
|
||||
*Do you want to be our agent now?
Contact us !
FAQ
---More than 12 years Electrical Equipment factory experiences
---Professional sales team and R & D team
---Qualified product and competitive price
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---We provide 1-2years warranty and 1% sapre parts for free
---We will repair the PCB or provide new one
Q3: What kind of certification you have?
---ISO9001,ISO14001, CE,ROHS,UL,and so on
---All series product pass different labor testing according to different countries’ requirements.
Q4: Delivery time:
---Standard products could be delivered within 7 days;
Q5. Can I have a sample order?
---Yes, we welcome sample order to test and check quality.
Q6. Do you have any MOQ?
---Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ,1 pc
for sample checking is available.
Q7. Do you support OEM?
---Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
