Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SUNNIEST
-
Model Number:
-
REVO VM II PRO series
-
Input Voltage:
-
230VAC
-
Output Voltage:
-
230Vac±5%
-
Size:
-
395*350*175mm/510*380*220mm
-
Weight:
-
7.7kg/9.5kg/10.8kg
-
Application:
-
Solar Power System
-
Waveform:
-
Pure Sine Wave
-
Frequency Range:
-
50Hz/6oHz (Auto sensing)
-
Transfer Time:
-
10ms (For Personal Computers); 20ms (For Home Appliances)
Quick Details
-
Output Type:
-
Three Phase
-
Type:
-
DC/DC Converters, DC/AC Inverters, AC to AC
-
Inverter Efficiency:
-
93.5%
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SUNNIEST
-
Model Number:
-
REVO VM II PRO series
-
Input Voltage:
-
230VAC
-
Output Voltage:
-
230Vac±5%
-
Size:
-
395*350*175mm/510*380*220mm
-
Weight:
-
7.7kg/9.5kg/10.8kg
-
Application:
-
Solar Power System
-
Waveform:
-
Pure Sine Wave
-
Frequency Range:
-
50Hz/6oHz (Auto sensing)
-
Transfer Time:
-
10ms (For Personal Computers); 20ms (For Home Appliances)
Detail Images
Products Description
Product Paramenters
|
Model
|
REVO VM II PRO
|
|
|
|
||||
|
Rated Power
|
1500VA/1500W
|
2500VA/2500W
|
3500VA/3500W
|
5500VA/5500W
|
||||
|
INPUT
|
|
|
|
|
||||
|
Voltage
|
230VAC
|
|
|
|
||||
|
Selectable Voltage Range
|
170-280VAC (For Personal Computers); 90-280VAC (For Home Appliances)
|
|
|
|
||||
|
Frequency Range
|
50Hz/60Hz (Auto sensing)
|
|
|
|
||||
|
OUTPUT
|
|
|
|
|
||||
|
ACVoltage Regulation (Batt. Mode)
|
230VAC±5%
|
|
|
|
||||
|
Surge Power
|
3000VA
|
5000VA
|
7000VA
|
11000VA
|
||||
|
Efficiency (Peak)
|
up to 93.5%
|
|
|
|
||||
|
Transfer Time
|
10ms (For Personal Computers); 20ms (For Home Appliances)
|
|
|
|
||||
|
Waveform
|
Pure Sine Wave
|
|
|
|
||||
|
BATTERY
|
|
|
|
|
||||
|
Battery Voltage
|
12VDC
|
24VDC
|
|
48VDC
|
||||
|
Floating Charge Voltage
|
13.5VDC
|
27VDC
|
|
54VDC
|
||||
|
Overcharge Protection
|
16VDC
|
33VDC
|
|
63VDC
|
||||
|
SOLAR CHARGER & AC CHARGER
|
|
|
|
|
||||
|
Maximum PV Array Open Circuit Voltage
|
500VDC
|
|
|
|
||||
|
Maximum PV Array Power
|
2000W
|
3000W
|
4500W
|
5500W
|
||||
|
MPPT Range @ Operating Voltage
|
120-450VDC
|
|
120-450VDC
|
|
||||
|
Maximum Solar Charge Current
|
100A
|
|
|
|
||||
|
Maximum AC Charge Current
|
80A
|
|
|
|
||||
|
Maximum AC Charge Current
|
60A
|
|
100A
|
|
||||
|
PHYSICAL
|
|
|
|
|
||||
|
Dimension, D*W*H (mm)
|
348*270*95
|
|
400*300*115
|
|
||||
|
Net Weight (kg)
|
4
|
5
|
8.5
|
9
|
||||
|
Communication Interface
|
Yes (optional)
|
|
|
|
||||
|
ENVIRONMENT
|
|
|
|
|
||||
|
Humidity
|
5% to 95% Relative Humidity (Non-condensing)
|
|
|
|
||||
|
Operating Temperature
|
-10℃ to 50℃
|
|
|
|
||||
|
Storage Temperature
|
-15℃ to 60℃
|
|
|
|
||||
