Quick Details
-
Application:
-
Driveway/Slope/Retaining Walls
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
OEM or Xinfeng
-
Model Number:
-
Smooth Geocell,Textured Geocell
-
Product name:
-
HDPE Geocell
-
Material:
-
HDPE PP
-
Color:
-
Black/Yellow/Green/White
-
THICKNESS:
-
1.0-1.7mm
-
Height:
-
50mm~250mm
-
Keyword:
-
Soil Stabilization Geocell Grid
-
Surface:
-
Textured Smooth
-
WELDING DISTANCE:
-
330mm-1000mm
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
total solution for projects
-
Application:
-
Driveway/Slope/Retaining Walls
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
OEM or Xinfeng
-
Model Number:
-
Smooth Geocell,Textured Geocell
-
Product name:
-
HDPE Geocell
-
Material:
-
HDPE PP
-
Color:
-
Black/Yellow/Green/White
-
THICKNESS:
-
1.0-1.7mm
-
Height:
-
50mm~250mm
-
Keyword:
-
Soil Stabilization Geocell Grid
-
Surface:
-
Textured Smooth
-
WELDING DISTANCE:
-
330mm-1000mm
|
Product Introduction:
Xinfeng Geocell is a lightweight and flexible three-dimensional, expandable panels made from High Density Polyethylene (HDPE) strips which are ultrasonically bonded together to form an extremely strong configuration.
Features and Benefits:
Light weight, wear-resistant, chemical stability, anti-ultraviolet, anti-acid/ alkali corrosion.
Wide temperature range adaptable, high tensile strength.
good rigidity and toughness, good load capacity and anti-erosion ability.
Size is variable, change the height and welding distance can meet the requirement of different projects.
|
|
Product Type
|
Height (mm)
|
Welding Distance (mm)
|
Thickness(mm)
|
Tensile Strength of Welding Points (N/cm)
|
Tensile Strength of Connection of Cells (N/cm )
|
Tensile Strength at Yield of Each Sheet (MPa)
|
|
Smooth and Not Perforated
|
50≤H≤300
|
300≤A≤1000
|
1.0 —1.2
|
≥100
|
≥120
|
≥20
|
|
Smooth and Perforated
|
50≤H≤300
|
300≤A≤1000
|
1.0 —1.2
|
≥100
|
≥120
|
≥20
|
|
Textured and Not Perforated
|
50≤H≤300
|
300≤A≤1000
|
1.3 —1.6
|
≥100
|
≥120
|
≥20
|
|
Textured and Perforated
|
50≤H≤300
|
300≤A≤1000
|
1.3 —1.6
|
≥100
|
≥120
|
≥20
|
|
Product mode
|
||||||
|
Height（mm）*Welding distance（mm）
|
50-330
|
50-356
|
50-445
|
50-660
|
50-712
|
Height：300mm we also can do it！
|
|
100-330
|
100-356
|
100-445
|
100-660
|
100-712
|
||
|
150-330
|
150-356
|
150-445
|
150-660
|
150-712
|
||
|
200-330
|
200-356
|
200-445
|
200-660
|
200-712
|
||
|
Remarks:
1. Color：black，green，gray，etc.
2.This is a basic technical specification.
3. All technical specifications can be reached according to customer's demand, other special standards please tell us.
|
||||||
|
Application:
To reinforce the roadbed of highway/railway.
To bear the pressure of dam, retaining wall.
To protect slope from landslide and mudslide.
To protect channel from water flowing.
To be used as independent wall, wharf and breakwater, etc.
Embankment construction of poor quality soils.
|
