Quick Details
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
Heng da
-
Dimension(L*W*H):
-
390x330x350
-
Weight:
-
15
-
Rated power/speed:
-
3000 / 3600rpm
-
Marketing Type:
-
New Product 2023
-
Product name:
-
Small Gasoline Engine
-
After Warranty Service:
-
Video Technical Support Online Support
-
Function:
-
Power Support
-
Cooling System:
-
Air Cold
-
Brand:
-
Heng da
-
Certification:
-
CE ISO
-
Rated Power:
-
3.5KW-9.2KW (4.8HP-12.5HP)
-
MOQ:
-
1 Set
-
Application:
-
Engineering Machinery
-
Packing:
-
Wooden Case Packing
Quick Details
-
Displacement:
-
125CC
-
Emission Standard:
-
Euro 6
-
Power:
-
4hp, 7HP, 5HP, 5 KW, 4.8 Kw, 4.5 KW, 5.5 KW
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
Heng da
-
Dimension(L*W*H):
-
390x330x350
-
Weight:
-
15
-
Rated power/speed:
-
3000 / 3600rpm
-
Marketing Type:
-
New Product 2023
-
Product name:
-
Small Gasoline Engine
-
After Warranty Service:
-
Video Technical Support Online Support
-
Function:
-
Power Support
-
Cooling System:
-
Air Cold
-
Brand:
-
Heng da
-
Certification:
-
CE ISO
-
Rated Power:
-
3.5KW-9.2KW (4.8HP-12.5HP)
-
MOQ:
-
1 Set
-
Application:
-
Engineering Machinery
-
Packing:
-
Wooden Case Packing
Products Description
Product Description
Introduction
This easymore gasoline engine has gas-saving overhead valves for cooler, cleaner performance and longer life. The horizontal shaft is ball-bearing mounted, making this Petrol Engine an ideal replacement for most standard engine configurations.
Tips: Everything is negotiable, Please contact us before placing an order. .
Tips: Everything is negotiable, Please contact us before placing an order. .
Machine Parameter
|
NAME
|
ITEM
|
LF168F/GX160
|
LF168F IGX200
|
LF170F/GX240
|
||
|
Gasoline
Engine
|
Engine Type
|
Air-cooled4-stroke,OHV;single cylinder
|
|
|
||
|
|
Bore Stroke(mm)
|
68x45
|
68x54
|
70-54
|
||
|
|
Displacement(cc)
|
163
|
196
|
210
|
||
|
|
Compression Ratio
|
8.5:1
|
8.5:1
|
8.5:1
|
||
|
|
Max.Power Output(KW)
|
(5.5HP)4.1
|
(6.5HP)4.8
|
(7.0HP)5.1
|
||
|
|
Rated Power Output(KW)
|
(4.0HP)3.0
|
(5.8HP)4.3
|
(6.0HP)4.4
|
||
|
|
Max.Torque(N.m)
Ignition System |
10.8
|
13.2
|
14
|
||
|
|
|
Transistor magnet
|
|
|
||
|
|
Start system
|
RecoiIIElectric
|
|
|
||
|
|
Engine Oil Capacity(L)
|
0.6
|
0.6
|
0.6
|
||
|
|
Fuel Capacity(L)
|
3.6
|
3.6
|
3.6
|
||
|
|
Min.Consumption of Fuel(g/kw.h
|
360
|
360
|
360
|
||
|
|
Power Take
|
Crankshaft or Camshaft
|
|
|
||
|
|
Crankshaft Direction
|
Left
|
|
|
||
|
|
Dimensions(LWH)(mm)
|
390x330x350
|
390x330x350
|
390x330x350
|
||
|
|
Net Weight(kg)
|
15
|
16
|
17
|
||
|
|
Air cleaner
|
Semi-dry , oil batch , Dual
|
|
|
||
Packing & Delivery
Packing:
Machine packing inside is plastic films and outside is fumigation wooden case.
Our wooden case is very strong,it can bear long time shipping on the sea.
And machine with preservative film, it can stop the salt sea water enter into the machine and make the machine corrosion.
Our wooden case is very strong,it can bear long time shipping on the sea.
And machine with preservative film, it can stop the salt sea water enter into the machine and make the machine corrosion.
Delivery:
For machines are big and heavy parcel, and different country with different delivery cost,so we suggest below delivery solution:
1. Over 1CBM or 100KG, we suggest send by Sea.
2. Below 1CBM or 100KG, we suggest send by Air.
3. Below 0.5CBM or 50KG, we suggest send by Express.
The price show on our website just the machine EXW price, please contact us for confirm delivery cost before you place order.
1. Over 1CBM or 100KG, we suggest send by Sea.
2. Below 1CBM or 100KG, we suggest send by Air.
3. Below 0.5CBM or 50KG, we suggest send by Express.
The price show on our website just the machine EXW price, please contact us for confirm delivery cost before you place order.
Certifications
Since its inception, STRONG MACHINE has been devoted to optimization and integration of developing, producing, sealing, and application of technology of ultrasonic machinery. After almost twenty years of unremitting efforts,
STRONG MACHINE
with high quality products, excellent technical support and perfect after-sales service has established a good reputation among the customers, and also gains a number of provincial and national honnors.
