Good toughness, easy to bend and not easy to break.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
JJ
-
Model Number:
-
BNG
-
Product name:
-
Explosion proof Flexible Conduit
-
Color:
-
Black
-
Application:
-
Electric Cable Wire Protection
-
Size:
-
G1/2" , G3/4"
-
Feature:
-
Corrosion Resistant
-
Usage:
-
Electrical Flexible Conduit Connector
-
Raw material:
-
PVC/ SS304
-
Length:
-
500mm/700mm/1000mm
-
OEM:
-
Offered
-
MOQ:
-
100 pcs
Quick Details
-
Type:
-
Flexible
-
Material:
-
PVC
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
JJ
-
Model Number:
-
BNG
-
Product name:
-
Explosion proof Flexible Conduit
-
Color:
-
Black
-
Application:
-
Electric Cable Wire Protection
-
Size:
-
G1/2" , G3/4"
-
Feature:
-
Corrosion Resistant
-
Usage:
-
Electrical Flexible Conduit Connector
-
Raw material:
-
PVC/ SS304
-
Length:
-
500mm/700mm/1000mm
-
OEM:
-
Offered
-
MOQ:
-
100 pcs
Explosion proof
Flexible Pipe Conduit
Products Description
Features
The tube thread can be replaced by G1/2", G3/4", G1" G1 1/4", G1 1/2", G2“ G2 1/2", G3" G4" etc
The minimum bending radius can be replaced by 80mm, 110mm, 145mm, 180mm, 210mm, 250mm, 350mm, 400mm, 500mm etc
The minimum bending radius can be replaced by 80mm, 110mm, 145mm, 180mm, 210mm, 250mm, 350mm, 400mm, 500mm etc
Technical Parameters
IP Degree: IP65
Waterproof Degree: WF2
The Bushings of the Flexible tubes can be choose inner Bushings, outer Bushings, or threaded plugs
|
Model
|
Tube Size(mm)
|
Tube Thread
|
Length(mm)
|
Minimum Bending Radius
|
Material
|
|
BNG-15*500
|
15
|
G1/2''
|
500
|
80MM
|
PVC rubber
|
|
BNG-15*700
|
15
|
G1/2''
|
700
|
80MM
|
|
|
BNG-15*1000
|
15
|
G1/2''
|
1000
|
80MM
|
|
|
BNG-II-20*500
|
20
|
G3/4''
|
500
|
110MM
|
304 Stainless Steel
|
|
BNG-II-20*700
|
20
|
G3/4''
|
700
|
110MM
|
|
|
BNG-II-20*1000
|
20
|
G3/4''
|
1000
|
110MM
|
|
Details Images
Various lengths, various models, and various connectors can be selected.
Efficient waterproof performance, can also be installed and used outdoors.
Application
1. The exterior is made of 304 stainless steel, IP65 grade anti-corrosion engineering rubber and stainless steel wire weaving materials, which are waterproof, explosion-proof, anti-corrosion and dust-proof. The bushing is made of stainless steel or carbon steel.
2. It can be bent arbitrarily, with strong tensile performance and easy installation
3. Heighten and thicken stainless steel joints. High-strength protection
4. The connection is deepened with threads, which will not fall off and will not slip easily.
5. The stainless steel flexible tube adopts a precision braided shell to protect the cable from aging and water seepage.
6. Can be used in hazardous locations of zone 0&1&2 and zone 20&21&22
7. Degree of protection IP65 and the types of connectors are complete.
3. Heighten and thicken stainless steel joints. High-strength protection
4. The connection is deepened with threads, which will not fall off and will not slip easily.
5. The stainless steel flexible tube adopts a precision braided shell to protect the cable from aging and water seepage.
6. Can be used in hazardous locations of zone 0&1&2 and zone 20&21&22
7. Degree of protection IP65 and the types of connectors are complete.
