Quick Details
-
Name:
-
4g lte module linux
-
Talk rang:
-
5000km
-
Dimension:
-
117mmx60mmx31mm
-
Weight:
-
213g
-
Working Rang:
-
UMTS/HSDPA 850/1900/2100
-
Maximum Output Power:
-
WCDMA 900/2100MHz/GSM/GPRS850/900MHz
-
Color:
-
black
-
Standby:
-
180h
-
power supply:
-
DC3.7V
-
Battery capacity:
-
3000MAH
Quick Details
-
Talk Range:
-
>50km
-
Place of Origin:
-
China
-
Brand Name:
-
redell
-
Name:
-
4g lte module linux
-
Talk rang:
-
5000km
-
Dimension:
-
117mmx60mmx31mm
-
Weight:
-
213g
-
Working Rang:
-
UMTS/HSDPA 850/1900/2100
-
Maximum Output Power:
-
WCDMA 900/2100MHz/GSM/GPRS850/900MHz
-
Color:
-
black
-
Standby:
-
180h
-
power supply:
-
DC3.7V
-
Battery capacity:
-
3000MAH
DS-560w
3000/5800mAh Lithium Battery
Group/Private/All Call Function
Record, Monitor
GPS(Optional)
Voice Broadcast
ANI Identification
PC Management platform
Micro USB Charge
Specification:
|
Type |
Parameter item |
Specification |
|
Machanical Properties |
Model No |
DS-550w |
|
117mmx60mmx31mm |
||
|
Weight |
213g |
|
|
Working Temperature |
-30℃~+75℃ |
|
|
Basic Parameter |
Working Voltage |
3.3V~4.2V(Standard 3.8v) |
|
Working Current |
250mA@UTMS 2100/900 |
|
|
Peak Current |
0.8A |
|
|
RF Parameter |
Working Rang |
UMTS/HSDPA 850/1900/2100 |
|
GSM/GPRS/EDGE 850/900/1800/1900 |
||
|
|
Maximum Output Power |
WCDMA 900/2100MHz:Power Class 3(+24dBm +2.5Bm/-1.5dBm) GSM/GPRS850/900MHz:Power Class(+33dBm +2.5Bm/-0.5dBm) GSM/GPRS1800/1900MHz:Power Class(+30dBm +2.5Bm/-0.5dBm) |
|
Receiving Sensitivity |
WCDMA 900: ≤-108dBm WCDMA 2100: ≤-109dBm GSM 850/900/1800/1900: ≤-106dBm |
|
|
GPS |
GPS |
GPS Posotioning,1.57542GHz |
|
Sensitivity |
Catch -144dBm,Track-159dBm |
|
|
Technology Standard |
Data Speed Rate |
GSM CS:UL 9.6kpbs/DL9.6kpbs GPRS: Muiti-solt Class 10 EDGE: Muiti-solt Class 10 WCDMA CS:UL 64kpbs/DL 64kpbs WCDMA CS:UL 64kpbs/DL 64kpbs WCDMA PS:UL 384kpbs/DL 384kpbs |
|
Protocol |
HSDPA/WCDMA/EDGE/GPRS/GSM |
Standard Accessories
