- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Gain:
-
2x30dBi
-
Connector:
-
2 x N Female
-
Frequency Range:
-
698-6000MHz
-
Polarization:
-
Vertical and Horizontal
-
VSWR:
-
2.0
Quick Details
-
Type:
-
UWB antenna
-
Brand Name:
-
Qifan - Signalplus
-
Model Number:
-
SDG-0760VH-30
-
Place of Origin:
-
Guangdong, China
-
Gain:
-
2x30dBi
-
Connector:
-
2 x N Female
-
Frequency Range:
-
698-6000MHz
-
Polarization:
-
Vertical and Horizontal
-
VSWR:
-
2.0
Recommend Products
High Gain MIMO sector Antenna
1700-2700MHz 2x20dBi
Click to know more.
700-4000MHZ 5G 4G Antenna
High Gain 2x16dBi
Click to know more.
Product Details
Specifications
|
Frequency Range
|
698-6000MHz
|
|
Gain
|
2x30dBi
|
|
Polarization
|
Vertical and Horizontal
|
|
Horizontal Beanwidth
|
9°
|
|
Vertical Beamwidth
|
8°
|
|
F/B Ratio
|
≥30dB
|
|
VSWR
|
≤2.0
|
|
Input Impedance
|
50Ω
|
|
Maximum input power
|
100W
|
|
Lightning protection
|
DC Ground
|
|
Connector
|
N Female
|
|
Dimensions
|
60x90cm
|
|
Antenna weight
|
2.5 kg
|
|
Mounting Mast Diameter
|
Φ35-50mm
|
|
Operating temperature
|
-40℃~85℃
|
|
Rated Wind Velocit
|
60m/s
|
Packing & Shipping
Packing
We have 10 years of experience packing and shipping abroad. We would make sure the goods arrive safely.
Shipping
We would help you choose the shipping option that makes the most sense for you. Provide the destination of your shipment, sort your results by time or cost to find the most cost-effective shipping service.
