Quick Details
-
After-sales Service:
-
Repair, Call Center and on-line Technical Support
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
YAEN
-
Model Number:
-
MP211
-
Color Print Speed:
-
None
-
Interface Type:
-
USB and Bluetooth
-
Max Paper Size:
-
58*40mm
-
Printing Method:
-
Thermal Line Printing
-
Language:
-
Multi-language Supported
-
Print command:
-
ESC/POS Emulation
-
Power supply:
-
5V Type C USB
-
Driver:
-
Win7/Win8/Win10
-
OS:
-
Windows Android IOS
-
Paper type:
-
Thermal Receipt Paper
-
Battery:
-
2000mAh
-
Products Status:
-
Stock
-
Warranty(Year):
-
1 year
Quick Details
-
Max. Resolution:
-
384dots/line
-
Black Print Speed:
-
50~70mm/s
-
Use:
-
Receipt Printer
-
After-sales Service:
-
Repair, Call Center and on-line Technical Support
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
YAEN
-
Model Number:
-
MP211
-
Color Print Speed:
-
None
-
Interface Type:
-
USB and Bluetooth
-
Max Paper Size:
-
58*40mm
-
Printing Method:
-
Thermal Line Printing
-
Language:
-
Multi-language Supported
-
Print command:
-
ESC/POS Emulation
-
Power supply:
-
5V Type C USB
-
Driver:
-
Win7/Win8/Win10
-
OS:
-
Windows Android IOS
-
Paper type:
-
Thermal Receipt Paper
-
Battery:
-
2000mAh
-
Products Status:
-
Stock
-
Warranty(Year):
-
1 year
Specification
Features:
1. Compact design with light weight
2. 2000Mah battery
3. Power off and standby can last 3 years
4. Convenient type C connection port for charging
5. 70mm/s high printing speed
6. Support USB (type C) and Bluetooth interfaces
7. Provide Android and IOS SDK
2. 2000Mah battery
3. Power off and standby can last 3 years
4. Convenient type C connection port for charging
5. 70mm/s high printing speed
6. Support USB (type C) and Bluetooth interfaces
7. Provide Android and IOS SDK
Specification:
|
ITEMS
|
|
PARAMETERS
|
|
|
Printing
|
Method
|
Thermal dot line printing
|
|
|
|
Resolution
|
203dpi, 8dots/mm
|
|
|
|
Speed (Max)
|
70mm/s
|
|
|
Paper
|
Width
|
58mm
|
|
|
|
Valid printing width
|
48mm
|
|
|
|
Thickness
|
60～80μm
|
|
|
|
Roller diameter
|
≤40mm
|
|
|
|
Loading
|
Easy loading mechanism
|
|
|
Interface
|
|
Bluetooth and USB
|
|
|
Command sets
|
|
Compatible with ESC/POS
|
|
|
Character Set
|
Font
|
ASCII:9×17,12×24, Multiple code pages support
|
|
|
Barcode Symbologies
|
1D
|
UPC-A, UPC-E, EAN8, EAN13, CODE39, ITF, CODEBAR, CODE128, CODE93
|
|
|
|
2D
|
QR code
|
|
|
Graphics
|
|
Support bitmap printing with different density and user defined bitmap printing (Max. 40K for per bitmap, and Max. 64K for total)
|
|
|
Detection
|
Sensors
|
Paper out/ low battery
|
|
|
LED indicator
|
|
Power (green)
|
|
|
|
|
Bluetooth (blue)
|
|
|
|
|
Charging (Green)
|
|
|
|
|
Error/Paper out (red)
|
|
|
Charging
|
Charger
|
5V/1A in adapter
|
|
|
|
Battery
|
1500mAh/3.7V battery
|
|
|
Physical characteristics
|
Working condition
|
-5°C ~ 50°C, 25% ~ 80% R.H, no-condensation
|
|
|
|
Storage condition
|
-40°C ~ 60°C, 5% ~ 95% R.H, no-condensation
|
|
|
|
Dimension
|
102.85*75.38*46.7 mm (W*D*H)
|
|
|
|
Weight
|
190g (without paper roll)
|
|
|
Software
|
SDK
|
Android and iOS
|
|
|
|
Driver
|
Win7/Win8/Win10
|
|
