Quick Details
-
Rolling thinckness:
-
2-3 mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Suhang
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
8*1.2*1.2 m
-
Weight:
-
5000 kg
-
Marketing Type:
-
Hot Product 2022
-
After-sales service:
-
engineers available overseas
-
Certification:
-
CE
-
Control system:
-
PLC(imported Brand)
-
Basic frame:
-
standard H beam
-
Color:
-
Blue or customized
-
Advantage:
-
High stability
-
Feature:
-
Easy operation
-
Automatic type:
-
Full automatic
-
Location:
-
Wuxi city, Jiangsu province
-
Spare parts:
-
Imported brands
Quick Details
-
Type:
-
roll forming machine
-
Tile Type:
-
Steel
-
Production Capacity:
-
8-15 m/min
-
Rolling thinckness:
-
2-3 mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Suhang
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
8*1.2*1.2 m
-
Weight:
-
5000 kg
-
Marketing Type:
-
Hot Product 2022
-
After-sales service:
-
engineers available overseas
-
Certification:
-
CE
-
Control system:
-
PLC(imported Brand)
-
Basic frame:
-
standard H beam
-
Color:
-
Blue or customized
-
Advantage:
-
High stability
-
Feature:
-
Easy operation
-
Automatic type:
-
Full automatic
-
Location:
-
Wuxi city, Jiangsu province
-
Spare parts:
-
Imported brands
|
No.
|
Item
|
Parameter
|
|
1
|
Coil material
|
2.0-3.0 mm steel(according to customer's request)
|
|
2
|
Rollers material
|
Gcr15 bearing steel, quenching (HRC55-58)
|
|
3
|
Shaft material
|
45#forge steel, thermal fining
|
|
4
|
Cutting blade
|
Cr12Mov, heat treatment(HRC58-62°)
|
|
5
|
Driving method
|
by chain
|
|
6
|
Working speed
|
8-15 m/min
|
|
7
|
Dimension
|
about 10*1.0*1.5 m (length*width*height)
|
|
8
|
Weight/ Container
|
about 5T/ one 40'GP
|
|
No.
|
Component
|
Quantity
|
|
1
|
Decoiler
|
1 set
|
|
2
|
Guiding
|
1 set
|
|
3
|
Roll forming
|
1 set
|
|
4
|
Hydraulic cutting
|
1 set
|
|
5
|
Out table
|
2 sets
|
|
6
|
Hydraulic station
|
1 set
|
|
7
|
PLC controller
|
1 set
|
|
8
|
Spare part&tools
|
1 box
|
Q1. Are you trading company or factory?
A1. We’re manufacturer, not just foreign trade company. We have a factory.
A1. We’re manufacturer, not just foreign trade company. We have a factory.
Q2. Why is your price higher than other suppliers’?
A2. Our machines use imported brands and domestic first-tier brands with fine workmanship, reasonable design. The price also varies according to different speed and structure.
Q3. Do your machines have good quality?
A3. Definitely yes. We pay high attention to quality. We have many regular customers domestic and abroad. We think only high quality machines will gain long-term cooperation with customers.
Q4. What information customers need to provide if they want to get the quotation?
A4. Customers need to provide us with profile drawing with exact specifications, material, material’s thickness and punching holes.
A2. Our machines use imported brands and domestic first-tier brands with fine workmanship, reasonable design. The price also varies according to different speed and structure.
Q3. Do your machines have good quality?
A3. Definitely yes. We pay high attention to quality. We have many regular customers domestic and abroad. We think only high quality machines will gain long-term cooperation with customers.
Q4. What information customers need to provide if they want to get the quotation?
A4. Customers need to provide us with profile drawing with exact specifications, material, material’s thickness and punching holes.
Q5. Can you make customized profile machines?
A5. Yes, we can design the machines according to customers’ needs
Q6. Do you have after-sales service?
A6. Definitely yes. We’ll provide one year free after-sales service. Even after one year, we can also support you when the
machines have problems. We’ll charge only when some spare parts need to be changed.
Q7. How can we trust you can make the machine?
A7. First, we won’t accept the order if we can’t make the machine. We’ll lose than customers if we fail. Second, all our machines need to be checked before delivery. Customers can arrange their friend or the inspection service to come to our factory to inspect the machine.
A5. Yes, we can design the machines according to customers’ needs
Q6. Do you have after-sales service?
A6. Definitely yes. We’ll provide one year free after-sales service. Even after one year, we can also support you when the
machines have problems. We’ll charge only when some spare parts need to be changed.
Q7. How can we trust you can make the machine?
A7. First, we won’t accept the order if we can’t make the machine. We’ll lose than customers if we fail. Second, all our machines need to be checked before delivery. Customers can arrange their friend or the inspection service to come to our factory to inspect the machine.
