Quick Details
-
Keyword:
-
Folding machine
-
Model Number:
-
ZD-3000V
-
Brand:
-
YASEN
-
Foldring time:
-
Five
-
Maximum folded width:
-
3000mm
-
The maximum No.of folds:
-
5/32 (fold/layer)
-
Maximum folding rate:
-
50 m/min
-
Rated voltage:
-
Rated voltage
Quick Details
-
Warranty:
-
1 Year
-
After-sales Service Provided:
-
Video technical support, Field installation, commissioning and training, Online support
-
Place of Origin:
-
Shanghai, China
-
Keyword:
-
Folding machine
-
Model Number:
-
ZD-3000V
-
Brand:
-
YASEN
-
Foldring time:
-
Five
-
Maximum folded width:
-
3000mm
-
The maximum No.of folds:
-
5/32 (fold/layer)
-
Maximum folding rate:
-
50 m/min
-
Rated voltage:
-
Rated voltage
1.Used for bedsheets, quilts, tablecloth etc., 1 fold to 5 folds, various folding program, meet
different
requirements
2.135°rotatable PLC controller, convenient for the workers to operate from different sides
3.Connect with flatwork ironing machine to realize ironing and folding by one workflow,
economize on manpower and increase production greatly
After sales service:
| The whole machine has been guaranteed for 1 years. |
| Providing lifelong technical support. |
| Guarantee of spare parts supply. |
| Engineers available to service machinery overseas. |
Product parameters:
|
Name: Automatic Linen Folder |
|||
|
ZD Series |
Model |
||
|
Attributes |
ZD-3000V |
ZD-3300V |
|
|
Max Feeding Width(mm) |
3000 |
3300 |
|
|
Max Folding(times) |
5 |
5 |
|
|
Folding Speed(m/min) |
10-50 |
10-50 |
|
|
Air Pressure(Mpa) |
0.65-1.0 |
0.65-1.0 |
|
|
Compressed air(m3/min) |
0.5 |
0.5 |
|
|
Compressed air inlet(mm) |
16 |
16 |
|
|
Motor Power(kw) |
1.5 |
1.5 |
|
|
Dimension WxDxH(mm) |
4350x2800x1800 |
4650x2800x1800 |
|
|
N.W.(kg) |
2200 |
2350 |
|
