Quick Details
-
Dimension (L*W*H):
-
330*172*218mm
-
Weight:
-
11KG, 11Kg
-
System Type:
-
Other
-
Communication Port:
-
Other
-
Grid connection:
-
Other
-
Nominal Voltage:
-
12.8V
-
Nominal Capacity:
-
100Ah
-
Max Charge/Discharge Current:
-
100A
-
Dimension:
-
330*172*218mm
-
Cycle Life:
-
5000 times(50% DOD)
-
Application:
-
Solar Energy Storage Systems
-
Warranty:
-
5 Years
-
Communication:
-
Bluetooth (optional)
-
Display:
-
Optional
Quick Details
-
Model Number:
-
12.8V 100Ah
-
Brand Name:
-
SmartPropel
-
Place of Origin:
-
Guangdong, China
-
Dimension (L*W*H):
-
330*172*218mm
-
Weight:
-
11KG, 11Kg
-
System Type:
-
Other
-
Communication Port:
-
Other
-
Grid connection:
-
Other
-
Nominal Voltage:
-
12.8V
-
Nominal Capacity:
-
100Ah
-
Max Charge/Discharge Current:
-
100A
-
Dimension:
-
330*172*218mm
-
Cycle Life:
-
5000 times(50% DOD)
-
Application:
-
Solar Energy Storage Systems
-
Warranty:
-
5 Years
-
Communication:
-
Bluetooth (optional)
-
Display:
-
Optional
Products Description
|
Electrical
Characteristics
|
Nominal Voltage
|
12.8V
|
|
|
Nominal Capacity
|
100Ah
|
|
|
Energy
|
1280Wh
|
|
|
Internal Resistance
|
≤40mΩ
|
|
|
Cycle Life
|
3000 Cycles @ 0.2C Charging/Discharging ,80% DOD; 5000 Cycles, 50% DOD
|
|
|
Self Discharge
|
≤3.5% per month at 25℃
|
|
Standard Charging
|
Max.Charging Voltage
|
14.0~14.6V
|
|
|
Charging Mode |
At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C, and then,changed continuously with constant voltage of
14.6V until the current was not more than 0.02C |
|
|
Charging Current
|
20A
|
|
|
Max.Charging Current
|
100A
|
|
Standard Discharging |
Discharging Current
|
100A
|
|
|
Max. Continuous Current
|
50Ah
|
|
|
Max.Pulse Current
|
300A(<3S）
|
|
|
Discharging Cut-off Voltage
|
10.0V
|
|
Operating Condition
|
Charge Temperature
|
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
|
|
|
Discharge Temperature
|
-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
|
|
|
Storage Temperature
|
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
|
|
|
Water Dust Resistance
|
IP65
|
|
Structure
|
Cell
|
LiFePO4
|
|
|
Casing
|
Plastic
|
|
|
Dimension(L*W*H)
|
330*172*218mm
|
|
|
Weight
|
Approx. 11Kg
|
|
|
Terminal
|
M8 / M6
|
|
Cell Equalization Function
|
≥3.4V (can be reset)
|
Equalized opening voltage
|
|
Cell equalization function
|
≥30mV (can be reset)
|
Equalizing the start voltage difference
|
|
|
≤20mV (can be reset)
|
Equalize the end voltage difference
|
SmartPropel 12V Solar Battery Features
Advantages:
◆Using the technology of lithium iron phosphate cell, superior safety, 5000 cycles, 10 years design service life.
◆Using the technology of lithium iron phosphate cell, superior safety, 5000 cycles, 10 years design service life.
◆Built-in BMS
automatic protection for over-charge, over discharge, over current and over temperature.
◆ Free of maintenance .
◆ Internal cell balancing.
◆ Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery.
◆ Wider temperature range:-20℃~60℃.
◆ Optional function: LCD screen and Bluetooth Function.
◆ Support maximum 16 batteries units series or parallels.
automatic protection for over-charge, over discharge, over current and over temperature.
◆ Free of maintenance .
◆ Internal cell balancing.
◆ Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery.
◆ Wider temperature range:-20℃~60℃.
◆ Optional function: LCD screen and Bluetooth Function.
◆ Support maximum 16 batteries units series or parallels.
