Quick Details
-
Brand Name:
-
JIANT
-
Model Number:
-
TUF-2000M
-
Keypad:
-
4 key tactile-feedback membrane
-
Power supply:
-
8-36VDC~24VDC
-
Temperature:
-
-30 ~ 90℃
-
Installation mode:
-
Clamp on/Insertion/Inline
-
Communication protocol:
-
MODBUS
-
Output:
-
OCT, MODBUS, RS485
-
Pipe diameters:
-
DN15mm~DN6000MM
-
Serial port:
-
RS485
-
Protection:
-
IP65
-
Flash memory:
-
RAM memory
Quick Details
-
Type:
-
Variable Area Water Flowmeters
-
Warranty:
-
12 Month
-
Place of Origin:
-
Shanghai,China
-
Brand Name:
-
JIANT
-
Model Number:
-
TUF-2000M
-
Keypad:
-
4 key tactile-feedback membrane
-
Power supply:
-
8-36VDC~24VDC
-
Temperature:
-
-30 ~ 90℃
-
Installation mode:
-
Clamp on/Insertion/Inline
-
Communication protocol:
-
MODBUS
-
Output:
-
OCT, MODBUS, RS485
-
Pipe diameters:
-
DN15mm~DN6000MM
-
Serial port:
-
RS485
-
Protection:
-
IP65
-
Flash memory:
-
RAM memory
Product Description
Technical features:
1, working power supply: 85-264VAC and isolated 24VDC dual power input interface,
2, power consumption: the working current is 50mA (not connected to the keyboard display and buzzer does not sound)
3, signal output: 1 standard isolation RS485 output,
1 channel isolated 4-20mA or 0-20mA active output
1 OCT output (programmable pulse width 6-1000ms, factory default 200ms).
1 isolation relay output, can output positive, negative, net cumulative pulse and various alarm signals
4, signal input: two three-wire PT100 platinum resistance input loop, can achieve heat measurement function (enthalpy difference method)
3 4-20mA input optional, accuracy 0.1%, can input pressure, liquid level, temperature and other signals, can also be used as a digital interface
5, display: 2×10 backlit Chinese characters or 2×20 character LCD display (Chinese and English bilingual options)
6, operation: 4×4 touch keyboard window operation.
7, other functions: automatic memory of the first 512 days, the first 128 months, the first 5 years of accumulated traffic and working status; Automatic memory of the first 64 times, power off time and flow, and can be automatically or manually replenished; And can be read by MODBUS protocol
Specification
|
Warranty
|
12 Month
|
|
Customized support
|
OEM, ODM, OBM, Software reengineering
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
JIANT
|
|
Model Number
|
TUF-2000M
|
|
Type
|
Variable Area Water Flowmeters
|
|
Keypad
|
4 key tactile-feedback membrane
|
|
Power supply
|
8-36VDC~24VDC
|
|
Temperature
|
-30 ~ 90℃
|
|
Installation mode
|
Clamp on/Insertion/Inline
|
|
Communication protocol
|
MODBUS
|
|
Output
|
OCT, MODBUS, RS485
|
|
Pipe diameters
|
DN15mm~DN6000MM
|
|
Serial port
|
RS485
|
|
Protection
|
IP65
|
|
Flash memory
|
RAM memory
|
