Quick Details
-
Productivity:
-
30
-
Place of Origin:
-
shandong
-
Weight:
-
3500 kg
-
Dimension(L*W*H):
-
1400*700*1650mm
-
Product name:
-
Concrete Pump Truck
-
Type:
-
Diesel Power
-
Usage:
-
Construction Profiles
-
Color:
-
Customers' Requirement
-
MOQ:
-
1
-
Size:
-
4300*2060*3680mm
-
Concrete pump:
-
Widely Used
-
Model:
-
s10
Quick Details
-
Power Type:
-
Electric anddiesel oil
-
Max. vertical conveying distance:
-
200M
-
Max. horizontal conveying distance:
-
500M
-
Productivity:
-
30
-
Place of Origin:
-
shandong
-
Weight:
-
3500 kg
-
Dimension(L*W*H):
-
1400*700*1650mm
-
Product name:
-
Concrete Pump Truck
-
Type:
-
Diesel Power
-
Usage:
-
Construction Profiles
-
Color:
-
Customers' Requirement
-
MOQ:
-
1
-
Size:
-
4300*2060*3680mm
-
Concrete pump:
-
Widely Used
-
Model:
-
s10
Products Description
1. The concrete mixer pump combined two machines into a machine; move easily, strong and flexible maneuverability. 2. This
concrete mixer and pump are operates by a worker only, it will save maintenance and labor costs. 3. PLC program control system,
stable and reliable, longer life. 4. Feeding, mixing, flip and pumping are all controlled by hydraulic power, saving operation
labor. High performance, high efficiency, high automation and high reliability.
concrete mixer and pump are operates by a worker only, it will save maintenance and labor costs. 3. PLC program control system,
stable and reliable, longer life. 4. Feeding, mixing, flip and pumping are all controlled by hydraulic power, saving operation
labor. High performance, high efficiency, high automation and high reliability.
Max theoretical concrete conveying capacity
|
30m3/h
|
Distribution valve model
|
S tube valves
|
Hopper capacity * filling height
|
500L* 1200mm
|
Pump motor power
|
30kw
|
Winding motor power
|
4kw
|
Hydraulic circuit form
|
Open circuit
|
Rated speed
|
1480Rmp
|
Oil tank volume
|
170L
|
Weight
|
3500kg
|
Concrete pumping pressure
|
9Mpa
|
Concrete cylinder size * length
|
180mm*800mm
|
Discharge mouth diameter
|
180mm
|
Mixing motor power
|
3*2kw
|
Water pump motor power
|
550w
|
|
Gravel: 30mm
|
Voltage
|
380v
|
Dimension(L*W*H)
|
4300*2060*3680(mm)
|
Details Images
Our Advantages
After-sales buyer evaluation, so that you can rest assured to buy the machine you need. If you are interested, you can send me an email, and we will choose the machine and accessories you need through negotiation.
