Steam Control System is an inportant part of Pasterurizer, It contains steam rate adjustable valve, plunger valve, steam pressure reducing valve, steam trap and steam filter. A good steam control system can guarantee the machine working stable. All of the steam valves are come from Spirax Sarco (England).
- Product Details
- {{item.text}}
Quick Details
-
Power:
-
Customized
-
Weight:
-
3000 KG
-
Dimension(L*W*H):
-
Standard Size
-
Name:
-
Dairy Production Plant
-
Material:
-
SUS304
-
Certification:
-
ISO9001
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
ShangWang
-
Voltage:
-
220V/380V
-
Power:
-
Customized
-
Weight:
-
3000 KG
-
Dimension(L*W*H):
-
Standard Size
-
Name:
-
Dairy Production Plant
-
Material:
-
SUS304
-
Certification:
-
ISO9001
About Us
Products Description
Milk Processing Line
Shangwang can provide multi-function dairy processing line. Such as pasteurized milk, UHT milk, stirred type yogurt, set type yogurt, drinking yogurt, cheese, butter, cream. A complete dairy processing line including milk receiving tanks, pasteurizer, separator, plate heat exchanger, pasteurizer, homogenizer, fermentation tank, pumps, filling machine, water treatment system, CIP station, etc. According to customers’ requirement, we can provide customized production line. We can provide the milk processing line with the capacity from 3tons per day to 200tons per day. And we can also provide both semi-automatic line and fully automatic production line.
Products Details
|
Material
|
SUS304/SUS316L
|
|
Capacity
|
1000L/H~20T/H
|
|
Voltage
|
Customzied
|
|
Application
|
Juice, Milk, yogurt
|
|
Power
|
2.95kw~15kw
|
|
Max Sterilizing Temperature
|
65℃~138℃
|
Steam Control system
Control Panel
Created for operators of every experience level, our integrated automation software is connected to a 10.1” touch screen interface, which gives operators an overview of the pasteurizer, including temperatures, pressures etc. Its performance is displayed in real time and, if there is a fault, the operator receives an immediate alert. If the automation solution is integrated in the line, the whole line can be viewed from one interface.
Divert System
The temperature of the product is verified both before and after the holding cell. Product can only continue out of the pasteurizer if it has been heated to the right temperature and held for the right length of time in the holding cell. If this is not the case, a signal is automatically sent to the divert valve, and the product is diverted back to the balance tank for recirculation.
Smart Balance Tank
A smart balance tank equipped with CIP washing ball, high level/low level transmitter. When the product at high level in the balance tank, the feeding pump will automaticlly stop. When the product at low level in the balance tank, the product pump will automaticlly stop.
|
Material
|
SUS304/SUS316L
|
|
Capacity
|
500L-10000L
|
|
CIP tank type
|
Alcali tank,acid tank.hot water tank,pure water tank
|
|
Cleaning recycles
|
Single circuit,double circuits,three circuits etc
|
|
Automation degrees
|
full auto,semi auto,manual.
|
|
Heating type
|
Electrical heating,steam heating
|
Steam control system
Steam Control System is an inportant part of Pasterurizer, It contains steam rate adjustable valve, plunger valve, steam pressure reducing valve, steam trap and steam filter. A good steam control system can guarantee the machine working stable. All of the steam valves are come from Spirax Sarco (England).
Electrical
Schneider Electric is one of the industrial pioneers of France. The world's top 500 companies, the world's top electrician companies. We use dual power switches, pneumatic components, inverters, circuit breakers, contactors, etc. to ensure electrical stability and long life.
Control system
Created for operators of every experience level, our integrated automation software is connected to a 10.1” touch screen interface, which gives operators an overview of the CIP system, including temperatures, pressures etc. Its performance is displayed in real time and, if there is a fault, the operator receives an immediate alert. If the automation solution is integrated in the line, the whole line can be viewed from one interface.
Delivery
Certification
