Quick Details
-
Model Number:
-
HS2403-24M
-
Molding Type:
-
Plastic Injection Mold
-
Mould Life:
-
100,000-1,000,000 Shots
-
Business Type:
-
OEM/ODM Customization
-
Color:
-
Custom, Double- Color, White, Clear, Natural, Black
-
Overall Solution:
-
YES
-
Inserts & Assembly:
-
Available
-
Cavity:
-
Single, Multi Cavities
-
Runner:
-
Hot, Cold Runner
-
Tolarance:
-
±0.01MM
-
MOQ:
-
1 PCS
Quick Details
-
Shaping Mode:
-
Injection Mold
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
hongsheng
-
Model Number:
-
HS2403-24M
-
Molding Type:
-
Plastic Injection Mold
-
Mould Life:
-
100,000-1,000,000 Shots
-
Business Type:
-
OEM/ODM Customization
-
Color:
-
Custom, Double- Color, White, Clear, Natural, Black
-
Overall Solution:
-
YES
-
Inserts & Assembly:
-
Available
-
Cavity:
-
Single, Multi Cavities
-
Runner:
-
Hot, Cold Runner
-
Tolarance:
-
±0.01MM
-
MOQ:
-
1 PCS
Service
Details:
|
Lead Time
|
Starts at 5 business days, including fast quote responses with design-for-manufacturing (DFM) feedback
|
|
Production Options
|
Domestic and international
|
|
Materials
|
Most plastics, including custom sourcing and matching; see materials list below
|
|
Machines Available
|
Single, multi-cavity, and family molds; 80 to 600+ press tonnage; side actions including hand-loaded cores.
|
|
Inspection and Certification Options
|
Includes FAI, PPAP, ISO 9001, BSCI, IAFT16949，RoHS, REACH, GS, UL,PSE...
|
|
Tool Ownership
|
Customer-owned with mold maintenance
|
|
Mold Cavity Tolerances
|
+/- 0.005″ when machining the mold and an additional +/- 0.002″ per inch when calculating for shrink rate
|
|
Part to Part Repeatability
|
+/- 0.004″ or less
|
|
Critical Feature Tolerances
|
Tighter tolerances can be requested and may increase the cost of tooling because of additional sampling and grooming. HS will mill
to a steel-safe condition on critical features. |
|
Available Mold Types
|
Steel and aluminum; Production grades range from Class 105, a prototype mold, to Class 101, an extremely high production mold. HS
typically produces Class 104, 103, and 102 tools. |
