Quick Details
-
Model Number:
-
strip cutter
-
Voltage:
-
as you need
-
Dimension(L*W*H):
-
1290*870*1550
-
Weight (KG):
-
19000 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Type:
-
Rubber Cutting Machine
-
Machine Type:
-
strip cutter
-
Histroy:
-
more than 30 years of professional tec...
-
Clients:
-
Exporting to more than 30 areas
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
guangyue
-
Marketing Type:
-
New Product 2025
-
Model Number:
-
strip cutter
-
Voltage:
-
as you need
-
Dimension(L*W*H):
-
1290*870*1550
-
Weight (KG):
-
19000 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Type:
-
Rubber Cutting Machine
-
Machine Type:
-
strip cutter
-
Histroy:
-
more than 30 years of professional tec...
-
Clients:
-
Exporting to more than 30 areas
Double Roller Rubber Crusher For Waste Tyre Recycle
Use :
To cut the waste tyre before crushing to rubber powders to be recycled .
1.Ring Cutter :
This machine mainly used to cut the sidewall of steel wire tire,and then to the next step of segmentation. First, put the tire on the platform, then rotate the hand wheel, the three claws will stick the inner tire firmly. Second ,Starting power. Work platform will rotation ,cutting tool according to need to cut tire slowly step by step, until the tire side cut off.
|
Item |
Specification |
|
motor power |
5.5 |
|
Speed of main screw |
46.8 r/min |
|
M ax Diameter of tyre |
1200mm |
|
Dimension |
1100*900*1700mm |
|
Purpose :To cut the steel ring from the t y re |
|
2.Strips Cutter :
Strips cutting machine can cut cycle machine to remove the wire tire sidewall cut into strips, and the width of the adjustable section. Two circular knives for special materials, hard and durable ,can be used repeatedly grinding for no more than 1200 steel tires.
|
Item |
Parameter |
|
Motor Power |
5.5kw |
|
Disc Diameter |
380mm |
|
Rotate Speed |
18.4r/min |
|
Dimension |
1290*870*1550 |
|
Purpose: To cut the old tyre in to strip |
|
3.Block Cutter
Block Cutter is designed to cut car ,truck and rear tractor tire. Range is up to 120cm truck tires.The tire cutter adds flexibility to your total tire cutting system by providing you the opportunities of accepting tires up to 120cm into your system. The unit also allows your system to cut 60-70 truck tires per hour or 120-150 car tires per hour. This machine possesses of unique structure ,advanced technology low energy consumption ,high efficiency ,long life and other advantage.
|
Item |
Specification |
Block cutter |
|
motor power |
11kw |
|
|
Speed of main screw |
420 r/min |
|
|
Out diameter of cutter |
200mm |
|
|
Dimension |
1130*830*1100 |
|
|
Purpose: To Cut the strip into block |
||
4.Bead Wire Remover
|
Item |
Specification |
|
Motor power |
15 KW |
|
Linear speed of front roller |
15.5 m/min |
|
Ratio of speed |
1.1 |
|
Dimension |
1520*1150*12101mm |
|
Purpose:To Separate the steel ring from the rubber after 1 step. |
|
Be utilized to separate rubber and steel wire of bead in order to get whole steel wire,
Feature: It is easy operation ,easy to be installed and maintained high efficiency and clean etc.
5.Wire Extractor
