Quick Details
-
Warranty:
-
1 year, 1 Year
-
Brand Name:
-
YINJIA
-
Model Number:
-
AUTOJET80
-
Place of Origin:
-
Fujian, China
-
Horsepower:
-
0.75HP
-
Cable Length:
-
71#L62
-
Outlet Size:
-
1''*1''
-
Power:
-
220V/50HZ, 0.5HP/0.37KW
-
Standard or Nonstandard:
-
Standard
-
Color:
-
Customer Specifications
-
Motor:
-
100% Copper Wire
-
In/out Let:
-
1''*1''
-
Name:
-
Agriculture Irrigation Tools
Quick Details
-
Application:
-
District Energy, Drinking water treatment, Family Homes, Irrigation and Agriculture, Washing and Cleaning
-
Pressure:
-
4.6 Bar, high Pressure
-
Voltage:
-
0.55KW, 220V/380V
-
Warranty:
-
1 year, 1 Year
-
Brand Name:
-
YINJIA
-
Model Number:
-
AUTOJET80
-
Place of Origin:
-
Fujian, China
-
Horsepower:
-
0.75HP
-
Cable Length:
-
71#L62
-
Outlet Size:
-
1''*1''
-
Power:
-
220V/50HZ, 0.5HP/0.37KW
-
Standard or Nonstandard:
-
Standard
-
Color:
-
Customer Specifications
-
Motor:
-
100% Copper Wire
-
In/out Let:
-
1''*1''
-
Name:
-
Agriculture Irrigation Tools
|
APPLICATION
-
Suitable for use with clean water, or non-aggressive liquids only, without sand or other solid impuritires.
-Suitable for lifting water from well, sprinkling irrigation in garden, pressure boosting of running water, or supporting equipment etc.
|
|
|
|
|
||||
|
OPERATING LIMITS
-Total suction lift up to 9 mt. with foot valve
-Max. operating pressure: 8 bar.
-Max. ambient temperature:+40℃
-Max. liquid temperature:+60℃
-Max. altitude:+1000 mt.
|
|
|
DESIGN FEATURES
-
Pump body/motor bracket: cast iron
-Impeller: Brass
-Bearing:C&U
-100% copper winding
-Built-in thermal protector for single phase motor
-Motor shaft:AISI 304 welded shaft
-Mechanical seal:Carbon/Ceramic/NBR/SUS304
-Butyl manbrane tank
-Flexible hose with connection
-Adjusted switch on/off pressure 1.38-2.76 bar with cable
-Pressure gauge
-Brass connection
|
|
||||
|
MOTOR
-Insulation class:B
-Protection: IP44
-Speed of rotation: 2850rpm
-Continuous duty:S1
|
|
|
|
|
||||
|
SPECIAL FEATURES ON REQUEST
-Anti-rust treatment for casting
-AISI 1045 motor shaft
-Carbon/SiC/V mechanical seal
-Insulation class:F
|
|
|
|
|
||||
FAQ
Q
: Are you a factory or trading company?
A
: We are a professional surface water pump manufacturer since 1990, located in Fuan, Fujian, China.
Q
: Do you provide OEM/ODM service?
A
: Yes, we are premium OEM/ODM manufacturer which assessed by independent third parties.
Q
: What is the feature of your products ?
A
: Our products have 3 obviously features: quite, powerful, heavy duty.
Q
: What is your MOQ ?
A
: 100 pcs per model for factory brand and package.
300 pcs per model for OEM brand and package.
Q
: How do you control the quality ?
A
: All production process strict to follow ISO9001 system, QC team check the quality during the production and do the test before each shipment.
Q
: What is your delivery time?
A
: 15 days for sample order, 30 days for container order. ( Busy season may need more days )
