- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
FIT-W8
-
Dimension:
-
230 (W) x 470(H) x 257(D)
-
Storage:
-
N/A
-
SNR:
-
---
-
Output Power:
-
120W@100V or 180W@8Ω
-
Shell Material:
-
Housing: ABS; Grille: Steel
-
Format:
-
N/A
-
Product Name:
-
Public address wall-mounted speaker
-
Max power:
-
180W@100V
-
SPL (1W / 1m):
-
96dB SPL (250 Hz-4 kHz)
-
MAX SPL(Rated / 1m):
-
118 dB SPL@110V
-
Frequency Response(-10dB):
-
70Hz~20kHz
-
Dispersion (4kHz / 1kHz):
-
115 degree (+46 degree /-46 degree,500Hz ~ 6kH)
-
Speaker Component:
-
120W 8Inch Stereo portable Wall mounted Hanging Speaker
-
Waterproof and dustproof grade:
-
IP66
-
Color:
-
FIT W8TB: Black; FIT W8TW: White
-
Certification:
-
CE, ROHS, IEC529, IP66
Quick Details
-
Warranty:
-
3months-1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DEKEN
-
Model Number:
-
FIT-W8
-
Dimension:
-
230 (W) x 470(H) x 257(D)
-
Storage:
-
N/A
-
SNR:
-
---
-
Output Power:
-
120W@100V or 180W@8Ω
-
Shell Material:
-
Housing: ABS; Grille: Steel
-
Format:
-
N/A
-
Product Name:
-
Public address wall-mounted speaker
-
Max power:
-
180W@100V
-
SPL (1W / 1m):
-
96dB SPL (250 Hz-4 kHz)
-
MAX SPL(Rated / 1m):
-
118 dB SPL@110V
-
Frequency Response(-10dB):
-
70Hz~20kHz
-
Dispersion (4kHz / 1kHz):
-
115 degree (+46 degree /-46 degree,500Hz ~ 6kH)
-
Speaker Component:
-
120W 8Inch Stereo portable Wall mounted Hanging Speaker
-
Waterproof and dustproof grade:
-
IP66
-
Color:
-
FIT W8TB: Black; FIT W8TW: White
-
Certification:
-
CE, ROHS, IEC529, IP66
8 Inch Full Range Design Big Party Pa Audio Sound System Custom Logo Outdoor Wall Mounted Speaker Box for School Classroom Hotel
Products Description
Specification:
FIT W series are compact waterproof fashion speakers. The use of international advanced mold, thickened high-strength ABS cabinet,and cleverly designed mounting bracket can respond to any installation requirements.
The dustproof and waterproof performance of the speaker is as high as IP66 grade, and it has been subjected to strict waterproof test when leaving the factory. It is widely used in various all-weather environments in pursuit of sound quality, such as commercial pedestrian street, bar street, villa, swimming pool, golf course, sports ground, etc. It also has extraordinary performance in indoor environments such as meeting room, banquet hall, and multi-function hall.
With 100V constant voltage or 8Ω version options. This series of speakers provide a wider range of versatile uses, whether professional audio applications or public broadcasting can be competent.
Optional black and white colors or various spray colors that can be customized at the factory can be adapted to more places. The user-friendly design of the mounting bracket can make the voluminous installation work accurate and fast, save the cost and time of installation, can adjust the angle of the speaker at will, and accurately control the sound field distribution.
Constant voltage version: FIT W5T/FIT W8T
Fixed impedance version: FIT W5L/FIT W8L
Features:
* All-weather speaker with a wide range of applications.
* Dustproof and waterproof grade conforms to IEC529 IP66 standard.
* Stunning and extraordinary sound quality.
* All-weather speaker designed for the professional audio and commercial audio markets.
* Excellent 8" coaxial unit.
* The treble is transparent, bright, soft and not irritating.
* The bass is surging, powerful and thick.
* With 100V constant voltage or 8Ω version options.
* The ABS cabinet and aluminum mesh can be repainted, the factory configuration is white, can be customized black or other colors.
* Specifically designed gravity cabinet to help improve directionality and versatile installation.
* The hidden mounting bracket provides quick and flexible installation.
The dustproof and waterproof performance of the speaker is as high as IP66 grade, and it has been subjected to strict waterproof test when leaving the factory. It is widely used in various all-weather environments in pursuit of sound quality, such as commercial pedestrian street, bar street, villa, swimming pool, golf course, sports ground, etc. It also has extraordinary performance in indoor environments such as meeting room, banquet hall, and multi-function hall.
With 100V constant voltage or 8Ω version options. This series of speakers provide a wider range of versatile uses, whether professional audio applications or public broadcasting can be competent.
Optional black and white colors or various spray colors that can be customized at the factory can be adapted to more places. The user-friendly design of the mounting bracket can make the voluminous installation work accurate and fast, save the cost and time of installation, can adjust the angle of the speaker at will, and accurately control the sound field distribution.
Constant voltage version: FIT W5T/FIT W8T
Fixed impedance version: FIT W5L/FIT W8L
Features:
* All-weather speaker with a wide range of applications.
* Dustproof and waterproof grade conforms to IEC529 IP66 standard.
* Stunning and extraordinary sound quality.
* All-weather speaker designed for the professional audio and commercial audio markets.
* Excellent 8" coaxial unit.
* The treble is transparent, bright, soft and not irritating.
* The bass is surging, powerful and thick.
* With 100V constant voltage or 8Ω version options.
* The ABS cabinet and aluminum mesh can be repainted, the factory configuration is white, can be customized black or other colors.
* Specifically designed gravity cabinet to help improve directionality and versatile installation.
* The hidden mounting bracket provides quick and flexible installation.
DRAWING & MOUNTING
|
Model
|
FIT W5T
|
FIT W5L
|
FIT W8T
|
FIT W8L
|
|
Rated power
|
60W@100V
|
90W@8Ω
|
120W@100V
|
180W@8Ω
|
|
Max power
|
90W@100V;
|
135W@8Ω
|
180W@100V;
|
270W@8Ω
|
|
SPL(1W / 1m)
|
93dB SPL (125 Hz-12.5 kHz @1/3 octave frequency band)
94dB SPL (250 Hz-4 kHz) |
93dB SPL (125 Hz-12.5 kHz @1/3 octave frequency band)
94dB SPL (250 Hz-4 kHz) |
95 dB SPL (125 Hz-12.5 kHz @1/3 octave frequency band)
96dB SPL (250 Hz-4 kHz) |
95 dB SPL (125 Hz-12.5 kHz @1/3 octave frequency band)
96dB SPL (250 Hz-4 kHz) |
|
Max SPL (Rated / 1m)
|
112 dB SPL@110V
|
115 dB SPL@8Ω
|
118 dB SPL@110V
|
120dB SPL@8Ω
|
|
Frequency response (-10dB)
|
80Hz~20kHz
|
80Hz~20kHz
|
70Hz~20kHz
|
70Hz~20kHz
|
|
Diffusion Angle (4kHz / 1kHz)
|
115 º cone (+46º/-46 º, 500Hz to 6kH)
|
115 º cone (+46º/-46 º, 500Hz to 6kH)
|
115 º cone (+46º/-46 º, 500Hz to 6kH)
|
115 º cone (+46º/-46 º, 500Hz to 6kH)
|
|
Power selection method
|
Phoenix terminal interface
|
Phoenix terminal interface
|
Phoenix terminal interface
|
Phoenix terminal interface
|
|
Material
|
Enclosure: ABS; Mesh cover: metal
|
Enclosure: ABS; Mesh cover: metal
|
Enclosure: ABS; Mesh cover: metal
|
Enclosure: ABS; Mesh cover: metal
|
|
Color
|
FS-W5T B: black;
FS-W5T W: white |
FS-W5L B: black;
FS-W5L W: white |
FS-W8T B: black; FS-W8T W: white
|
FS-W8L B: black; FS-W8L W: white
|
|
Operating temperature/humidity
|
-30°C ~ 60°C; <95%
|
-30°C ~ 60°C; <95%
|
-30°C ~ 60°C; <95%
|
-30°C ~ 60°C; <95%
|
|
Dustproof and waterproof grade
|
IEC529 IP66
|
IEC529 IP66
|
IEC529 IP66
|
IEC529 IP66
|
|
Speaker unit
|
5.25" coaxial unit
|
5.25" coaxial unit
|
8" coaxial unit
|
8" coaxial unit
|
|
Dimensions
|
192 (W) x 328(H) x 160(D)
|
192 (W) x 328(H) x 160(D)
|
230 (W) x 470(H) x 257(D)
|
230 (W) x 470(H) x 257(D)
|
|
Weight (1 pc)
|
5.7kg
|
6kg
|
8.5kg
|
9kg
|
|
Installation
|
Hidden mounting bracket
|
Hidden mounting bracket
|
Hidden mounting bracket
|
Hidden mounting bracket
|
|
Gross weight
|
13.4kg, 2 pcs
|
14kg, 2 pcs
|
19 kg, 2 pcs
|
20 kg, 2 pcs
|
Application Cases
Suitable occasions:
Airports, Bus stations, Hotels, Office buildings, Gyms, Villas, Homes, Schools, Bar spas,KTV ,Saunas, Parks,
stage performances, dance halls, live audio recording, music screening rooms and other places
.......
