Quick Details
-
Model Number:
-
Servo motor
-
Frequency:
-
50hz
-
Motor model:
-
180ST-M35015
-
Rated Voltage (V):
-
380
-
Rated Power (W):
-
5500
-
Rated Torque (N.m):
-
35
-
Rated Current(A):
-
5
-
Rated Speed (rpm):
-
1500
-
Encoder Line Number (ppr):
-
2500
-
Insulation Class:
-
Class F
-
Safety Class:
-
IP65
-
Environment:
-
Temperature: -20~+50℃ Humidity Below 90%RH No Dewing
Quick Details
-
AC Voltage:
-
380V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
AoNing
-
Model Number:
-
Servo motor
-
Frequency:
-
50hz
-
Motor model:
-
180ST-M35015
-
Rated Voltage (V):
-
380
-
Rated Power (W):
-
5500
-
Rated Torque (N.m):
-
35
-
Rated Current(A):
-
5
-
Rated Speed (rpm):
-
1500
-
Encoder Line Number (ppr):
-
2500
-
Insulation Class:
-
Class F
-
Safety Class:
-
IP65
-
Environment:
-
Temperature: -20~+50℃ Humidity Below 90%RH No Dewing
Product Description
We are a professional manufacturer of servo motors with a full range of products.
Contact us for a catalogue to view all products and quotes
|
Motor Model
|
180ST-M35015
|
|
|
Rated Voltage (V)
|
380
|
|
|
Rated Power (KW)
|
5.5
|
|
|
Rated Torque (N.m)
|
35
|
|
|
Peak Torque (N.m)
|
30
|
|
|
Rated Current (A)
|
5
|
|
|
Rated Speed (rpm)
|
1500
|
|
|
Torque Coefficient (N.m/A)
|
0.33
|
|
|
Rotor Inertia (KG.M
2
)
|
2.77x10
-
3
|
|
|
Rotor Inertia with Brake (KG.M
2
)
|
2.8x10
-3
|
|
|
Line-line Resistance (Ω)
|
3.27
|
|
|
Line-line Inductant (mH)
|
12.36
|
|
|
Electrical Time-constant (ms)
|
3.77
|
|
|
Encoder Line Number (ppr)
|
2500
|
|
|
Insulation Class
|
ClassF
|
|
|
Safety Class
|
IP65
|
|
|
Environment
|
Temputer: -20~+50℃ Humidity Below 90%RH No Dewing
|
|
|
Weight(kg)
|
12.6
|
|
|
Our motors can replace a wide range of global brands, with excellent quality and reasonable price.
|
|
|
