Quick Details
-
Brand Name:
-
Lumiax
-
Model Number:
-
SMR-MPPT1050/BT
-
Work Time (h):
-
24h
-
Max PV Power:
-
130W
-
Max PV Voltage:
-
45V
-
Certificate:
-
CE,ISO9001,ISO14001,RoHS
-
Warranty:
-
3 years
-
Delivery time:
-
2-3 days
-
Certification:
-
CE,ISO9001,ISO14001
-
Battery type:
-
Gel,Liquid,AGM, Lithium,lifepo4
-
MPPT Tracking Efficiency:
-
>99.9%
-
Max Solar Voltage:
-
45V
-
Casing protection:
-
IP67
-
Full protection:
-
Yes
-
ODM,OEM service:
-
accepted
-
Self-consumption:
-
6mA
-
Display:
-
LED Display
Quick Details
-
Type:
-
MPPT
-
Application:
-
Charger Controller, Lighting Controller, Voltage Controller, Solar System Controller, RVS, Portable solar system
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Lumiax
-
Model Number:
-
SMR-MPPT1050/BT
-
Work Time (h):
-
24h
-
Max PV Power:
-
130W
-
Max PV Voltage:
-
45V
-
Certificate:
-
CE,ISO9001,ISO14001,RoHS
-
Warranty:
-
3 years
-
Delivery time:
-
2-3 days
-
Certification:
-
CE,ISO9001,ISO14001
-
Battery type:
-
Gel,Liquid,AGM, Lithium,lifepo4
-
MPPT Tracking Efficiency:
-
>99.9%
-
Max Solar Voltage:
-
45V
-
Casing protection:
-
IP67
-
Full protection:
-
Yes
-
ODM,OEM service:
-
accepted
-
Self-consumption:
-
6mA
-
Display:
-
LED Display
Product Paramenters
|
SMR-MPPT1050-BT with Bluetooth
SMR-MPPT1050-RS485 with RS485
|
|
ltem
|
SMR-MPPT1050
|
SMR-MPPT1575
|
SMR-MPPT2075
|
||
|
Max Charging Current
|
10A
|
15A
|
20A
|
||
|
System Voltage
|
12V
|
12V/24V automatical recognization
|
|
||
|
MPPT Charging Voltage
|
<14.5V@25℃
|
<14.5/29V@25℃
|
|
||
|
Boost Voltage
|
14.0~14.8V/28.0~29.6V(Default 14.5/29.0V@25℃,Programmable)
|
|
|
||
|
Equalization Voltage
|
14.0~15.0V/28.0~30.0V(Default 14.8/29.6v@25℃,Liquid/AGM,Programmable)
|
|
|
||
|
Float Voltage
|
13.0~14.5V/26.0~29.0V(Default 13.7/27.4V@25℃,Programmable)
|
|
|
||
|
Low Volt. Disconnect
|
10.8~11.8V/21.6~23.6V; SOC1~5(Default: 11.2/22.4V,Programmable)
|
|
|
||
|
Reconnect Voltage
|
11.4~12.8V/228~25.6V(Default 12.0/24.0V,Programmable)
|
|
|
||
|
Overcharge Protect
|
15.5V
|
15.5/31.0V
|
|
||
|
Temp.Compensation
|
-4.17mV/K per cell (Boost,Equalization)，-3.33mV/K per cell (Float)
|
|
|
||
|
Charging voltage target
|
10.0~17.0V
|
10.0~32.0V(Lithium,Programmable)
|
|
||
|
Charging voltage recovery
|
9.2~16.8V
|
92~31.8V(Lithium,Programmable)
|
|
||
|
Low voltage disconnect
|
9.0~15.0V
|
9.0~30.0V(Lithium,Programmable)
|
|
||
|
Low voltage reconnect
|
9.6~16.0V
|
9.6~31.0V(Lithium,Programmable)
|
|
||
|
Battery Type
|
Lithium,Liquid,Gel,AGM (Programmable, default Gel)
|
|
|
||
|
0℃ Charge Protection
|
Yes,No,Slow(Lithium, default:Yes)
|
|
|
||
|
Max input power
|
130W
|
200W/400W
|
260W/520W
|
||
|
Max volt on Bat.Terminal
|
25V
|
35V
|
|
||
|
Max volt on PV terminal
|
45V
|
55V
|
|
||
|
Dusk/Dawn detect volt.
|
3.0~8.0V
|
3.0~20.0V(Programmable)
|
|
||
|
Day/Night delay time
|
0~30Min(Programmable)
|
|
|
||
|
MPPT tracking range
|
(Battery Voltage + 1.0v) ~Voc*0.9
|
|
|
||
|
Max tracking efficiency
|
>99.9%
|
|
|
||
|
Output Current
|
10A
|
15A
|
20A
|
||
|
Max charge conversion
|
96.50%
|
97.50%
|
|
||
|
Self consumption
|
6mA
|
|
|
||
|
Dimensions
|
85.8*81*23.1mm
|
85.8*145* 30mm
|
85.8*145* 42.5mm
|
||
|
Weight
|
260g
|
600g
|
720g
|
||
|
Ambient temperature
|
-35~+60℃
|
|
|
||
|
Ambient humidity
|
0~100%RH
|
|
|
||
|
Protection degree
|
IP67
|
|
|
||
|
Max Altitude
|
4000m
|
|
|
||
