Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
BESINO
-
Model Number:
-
BESINO-Polyurethane-950,1000
-
Product name:
-
Polyurethane Sandwich Panel/PU
-
Width:
-
950mm
-
Panel Length:
-
According to customers' request /Customizable
-
Core:
-
Polyurethane
-
Core Thickness:
-
50mm 75mm 100mm 120mm
-
Density of core:
-
35-45kg/m3
-
Steel Thinckness:
-
0.3mm-0.8mm
-
Steel Color:
-
White, gray, blue, red, etc
-
Galvanized layer of steel plates:
-
Exterior plate and Inner plate: Aluzinc or Zinc coating
-
Metal Sheet:
-
Color Coated Steel Sheet / Stainless steel plate
Quick Details
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
Warehouse
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
BESINO
-
Model Number:
-
BESINO-Polyurethane-950,1000
-
Product name:
-
Polyurethane Sandwich Panel/PU
-
Width:
-
950mm
-
Panel Length:
-
According to customers' request /Customizable
-
Core:
-
Polyurethane
-
Core Thickness:
-
50mm 75mm 100mm 120mm
-
Density of core:
-
35-45kg/m3
-
Steel Thinckness:
-
0.3mm-0.8mm
-
Steel Color:
-
White, gray, blue, red, etc
-
Galvanized layer of steel plates:
-
Exterior plate and Inner plate: Aluzinc or Zinc coating
-
Metal Sheet:
-
Color Coated Steel Sheet / Stainless steel plate
Product Description
●Concealed nail connection is adopted, and the lap of the board is tight.
● Unique waterproof groove design effectively prevents rainwater leakage and avoids cold bridge phenomenon.
● 50mm c
rest height, which greatly improves the bearing capacity of roof panels. While
ensuring the heat preservation effect of the building, it effectively reduces the construction cost of customers, and the roof slope can be as low as 3%.
|
Product Name
|
PU Sandwich Panel
|
|
Width
|
950 mm 970 mm 1000 mm 1150 mm
|
|
Panel Length
|
According to customers’ request
|
|
Core
|
PU core
|
|
Core Thickness
|
50mm,75mm,100mm,150mm, 200mm
|
|
Density Of Core
|
38kg-42kg/m3
|
|
Steel Thinckness
|
0.3 mm-0.8 mm
|
|
Steel Color
|
RAL color
|
|
Galvanized Layer Of Steel Plates
|
Exterior plate and Inner plate: Aluzinc or Zinc coating
|
|
Metal Sheet
|
Color Coated Steel Sheet / Stainless steel plate
|
|
Company Advantage
|
1.We are manufacturer.
2.We have more than 10 years experience.
3.We promise the high quality.
4.We have our own technical team.
|
The production of polyurethane sandwich panel requires advanced continuous production line of sandwich panel, and the process is cold-formed inside and outside galvanized (aluminized zinc) color steel plate, coated with polyurethane hard foam compound in the middle.
Effective width: 950mm
Available thickness: 50mm, 75mm, 100mm, 120mm
