Quick Details
-
Volume:
-
10L,15L,20L,30L,50L,70L,100L,200L,300L,500L
-
Feeding volume:
-
70%
-
Speed control:
-
Intelligent PID control,50-1000rpm,accuracy ± 5 ‰
-
PH/DO sensor:
-
PID control,range: 2.00-12.00±0.05pH,
-
Material:
-
Stainless Steel 304/316
-
Defoaming control:
-
PID control,100-100000Ω
-
Ventilation:
-
1: 1-2VVM
-
Pressure:
-
0-0.3MPa
-
Sterilization:
-
sterilization reign or off-site
-
Exhaust:
-
Stainless steel condenser exhaust
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Bailun
-
Weight:
-
400 KG
-
Volume:
-
10L,15L,20L,30L,50L,70L,100L,200L,300L,500L
-
Feeding volume:
-
70%
-
Speed control:
-
Intelligent PID control,50-1000rpm,accuracy ± 5 ‰
-
PH/DO sensor:
-
PID control,range: 2.00-12.00±0.05pH,
-
Material:
-
Stainless Steel 304/316
-
Defoaming control:
-
PID control,100-100000Ω
-
Ventilation:
-
1: 1-2VVM
-
Pressure:
-
0-0.3MPa
-
Sterilization:
-
sterilization reign or off-site
-
Exhaust:
-
Stainless steel condenser exhaust
Material: 316L stainless steel inside and 304 jacket
The diameter and hight ratio: 1:2-3
Mixing method: magnetic stirring or mechanical stirring one of the two optional
Sterilization method: on-site sterilization auto control or manual control
Control system: Siemens PLC, industrial LCD touch computer control, parameters can be set to store,
can be remotely connected to the computerthrough the USB interface, the data
Stirring system
Mechanical sealing system : high-powered stirring oar, antifoam oar; AC electrical machine:
infinite speed variation; rpm in the fermenter: 50~1000rpm±1%,The height of the stirring oar can be adjusted, too.
Temperature detection and control
Heat by thermostatic water tank and circulate by circulating pump(Grundfos, Denmark),
autocontrol (cooling water+5℃) to 65℃±0.1℃,temperature probe(US)
pH detection and control
2.00-12.00±0.05pH, autocontrol by adding acid and base, pH sensor (Mettler, Switzerland)
and shielding lead (Mettler, Switzerland). fermenter is autocontrolled with peristaltic pump
DO detection and control
0-150±3% displaying precision 0.1%, sensor (Mettler, Switzerland) and shielding lead(Mettler, Switzerland)
Feed control
Uses peristaltic pump (Longe) to add meterials
Antifoam control
Tested by sencor and added antifoamer by peristaltic pump
Intake control (air) manual control rotameter
pressure detection and control
Pressure Control: Pressure meter and digital display and digital remote control, pressure control
we are compliant fermentation equipment for research, development, pilot and production applications.
Our Factory in China.
We provide the fermentor products including : Stainless steel fermenter, Pilot combo stainless steel fermentor, glass fermentor, fermenter, Multi-Union fermenter,Multi-stagefermentation tank,and shaking Incubators ,
Positive join stainless steel fermentor.
Our other main product Glass fermenter bioreactor :
