Quick Details
-
MF:
-
-
-
EINECS No.:
-
-
-
Place of Origin:
-
jiangsu
-
Brand Name:
-
ZC
-
Model Number:
-
191
-
Appearance:
-
Light yellow transparent thick liquid
-
Acid value:
-
19-25
-
viscosity,25℃:
-
0.30-0.60
-
Solid content:
-
59-65
-
Gel time,25℃:
-
6-18
-
Heat stability 80℃:
-
≥24 h
-
Package:
-
220 Kg/drum
-
Sample:
-
free
-
Keywords:
-
unsaturated polyester resin
-
Delivery Time:
-
7 Days
Quick Details
-
CAS No.:
-
-
-
Purity:
-
100%
-
Other Names:
-
unsaturated polyester resin
-
MF:
-
-
-
EINECS No.:
-
-
-
Place of Origin:
-
jiangsu
-
Brand Name:
-
ZC
-
Model Number:
-
191
-
Appearance:
-
Light yellow transparent thick liquid
-
Acid value:
-
19-25
-
viscosity,25℃:
-
0.30-0.60
-
Solid content:
-
59-65
-
Gel time,25℃:
-
6-18
-
Heat stability 80℃:
-
≥24 h
-
Package:
-
220 Kg/drum
-
Sample:
-
free
-
Keywords:
-
unsaturated polyester resin
-
Delivery Time:
-
7 Days
Product description
Z191 resin raw material is anhydride, anhydride, and standard diol, dissolved in styrene , features medium viscosity and viscosity, proper rigidity and strength, fast post cure, excellent mechanical property, widely used, suitable for normal FRP products.
Liquid unsaturated polyester resin properties
| Item | range | Unit | Testing method |
| Appearance | Light yellow transparent thick liquid | — | — |
| Acid value | 19-25 | mgKOH/g | GB/T 2895 |
| viscosity , 25℃ | 0.30-0.60 | Pa.s | GB/T 7193.4.1 |
| Solid content | 59-65 | % | GB/T 7193.4.3 |
| Gel time , 25℃ | 6-18 | min | GB/T 7193.4.1 |
| Heat stability 80 ℃ | ≥ 24 h | h | GB/T 7193-2008 |
Note : 25℃ gel time testing : resin 50g filled in 0.9g T-8M(1% Co) and 0.9g M-50 (Akzo-Nobel)
Resin casting body property
|
Item |
Unit |
Measured data |
Testing method |
|
Appearance |
Casting body no fault |
— |
— |
|
Barcol hardness |
42 |
— |
GB/T 3854-2005 |
|
Tensile strength |
MPa |
60 |
GB/T2567-2008 |
|
Tensile modulus |
Mpa |
3800 |
GB/T 2567-2008 |
|
elongation at break |
% |
2.2 |
GB/T2567-2008 |
|
Bending strength |
MPa |
110 |
GB/T2567-2008 |
|
Bending modulus |
MPa |
3800 |
GB/T 2567-2008 |
|
Impact strength |
KJ/m 2 |
7.8 |
GB/T2567-2008 |
|
Distortion temperature |
℃ |
60 |
GB/T1634-2004 |
FRP physical property
| Item | Typical data | Unit | Testing method |
| Barcol hardness | 64 | — | GB/T 3584-2005 |
| Bending strength | 300 | Mpa | GB/T 1449-2005 |
| Bending modulus | 17000 | Mpa | GB/T 1449-2005 |
| Tensile strength | 320 | Mpa | GB/T 1447-2005 |
| Tensile modulus | 16000 | Mpa | GB/T 1447-2005 |
Liquid resin package and storage conditions
1.Packed in metal barrel , 220kg/barrel (about 55 gallons).
2.Try to prevent liquid resin from directly sunshine and heat resource.
3.Flammable, should keep away from open fire.
4.Shelf life is 3 month under 25℃.
5.Store and operate in a dry, well-ventilated place.
Please read MSDS carefully before use this product.
1. Q: Is your company a manufacturer?
A: Yes,we are. At the same time, we are also agents of other product brands.
2. Q: Does your company provide samples?
A: Yes,If you have a shipper in China ,sample will sent to him freely .
3. Q:How long could the resin be stored ?
A: Normally , 90 days .but if promoted resin ,it's about 45 days .
4. Q: If I will get a better price with big QTY ?
A: Of course , best price will be granted u as per QTY.
