- Product Details
- {{item.text}}
Quick Details
-
Voltage:
-
380V/50HZ/3PH
-
Dimension(L*W*H):
-
890*650*830MM
-
Weight:
-
190KGS
-
Air capacity:
-
0.33-1.04m3/min
-
Product name:
-
Rotary Screw Air Compressor
-
Power:
-
7.5KW 10HP
-
Capacity:
-
0.285-0.855M3/MIN @10Bar
-
Cooling method:
-
Air Cooling
-
Compressor Stage:
-
Single Stage
-
Certification:
-
CE,ROHS
-
Drive method:
-
Direct Driven
-
Connector size:
-
G1/2''
-
Speed:
-
2950RPM
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
AIRSTONE
-
Model Number:
-
AS-10PMC
-
Voltage:
-
380V/50HZ/3PH
-
Dimension(L*W*H):
-
890*650*830MM
-
Weight:
-
190KGS
-
Air capacity:
-
0.33-1.04m3/min
-
Product name:
-
Rotary Screw Air Compressor
-
Power:
-
7.5KW 10HP
-
Capacity:
-
0.285-0.855M3/MIN @10Bar
-
Cooling method:
-
Air Cooling
-
Compressor Stage:
-
Single Stage
-
Certification:
-
CE,ROHS
-
Drive method:
-
Direct Driven
-
Connector size:
-
G1/2''
-
Speed:
-
2950RPM
Title:Airstone Small 7.5KW 10HP Permanent Magnet Inverter Rotary Screw Air Compressor AS-10PMC Set 8 Bar 10Bar 380V 50HZ IP23
| Model Number | AS-120PMC |
| Horsepower | 90KW/120HP |
| Pressure | 7/8/10/12/13Bar |
| Capacity | 10M3/MIN |
| Driven method | Direct Driven |
| Ambient temperature | -5 to 50 DEGREE |
| Positive and negative rotor | Third generation a type asymmetrical 5:6 tooth |
| Rotor/Bearing working life time | 30Million/10Million |
| Connection size | G2'' |
| Lubricant oil | 35L |
| Noise | 75dB(A) |
| Dimensions | 1900*1250*1570MM |
BASIC CONFIGURATION
| Airend | Hanbell/Boaosi |
| Valve | Red Star |
| Controller | Plot |
| Contractor | CHINT/SIEMENS |
Comments is the only criterion for verifying quality
Choosing us is the first step towards success
Q1:Which horsepower can we provide?
A1:From 3.7KW/5HP to 250KW/350HP,frpm 3.7KW/5HP-7.5KW/10HP,we can also provide the Single Phase.
Q2:Which voltage can we provide?
A2:We can provide 380V/50HZ/3PH(Normal type,in general,in stock),220V/60HZ,415V/50HZ,380V/60HZ,440V/60HZ,600V/60HZ.(10-15days)
Q3:Which kind of package can we provide?
A3:Pallet,Wooden box or Wooden frame.
Q4:Which connection method can we provide?
A4:Belt driven from 7.5KW/10HP-45KW/60HP,direct driven from 3.7 KW /5 HP- 250 KW /350 HP
Q5:Which pressure can we provide?
A5:4-40Bar
We can also provide variable speed,permanent magnet variable speed and 4 in 1 air compressor.
Only you can't think of it,nothing we can't do it.
Any questions,welcome to contact me anytime.
