Quick Details
-
Warranty:
-
12 Months
-
Brand Name:
-
YINJIA
-
Model Number:
-
JSm37
-
Place of Origin:
-
Fujian, China
-
Horsepower:
-
0.5hp
-
Outlet Size:
-
1''x1''
-
Power:
-
0.37KW
-
motor:
-
AC Motor
-
Usage:
-
Pumping Water
-
Standard or Nonstandard:
-
Standanrd
-
Pump body:
-
Stainless Steeel
-
Impeller:
-
Brass/PPO/SS304 Impeller
-
MOQ:
-
100 Pcs
-
Fuel:
-
AC Electric Induction Motor
-
Motor:
-
100% Copper Wire
-
Color:
-
Customized Colors
-
Package:
-
1pcs/carton
Quick Details
-
Application:
-
Commercial Buildings, Developing World Water Solutions, District Energy, Drinking water treatment, Family Homes, Industrial Boilers, Industrial Utilities, Irrigation and Agriculture, Machining, Mining industry, temperature control, Washing and Cleaning, Water Distribution, Water Treatment Solutions
-
Pressure:
-
High Pressure
-
Voltage:
-
220V
-
Warranty:
-
12 Months
-
Brand Name:
-
YINJIA
-
Model Number:
-
JSm37
-
Place of Origin:
-
Fujian, China
-
Horsepower:
-
0.5hp
-
Outlet Size:
-
1''x1''
-
Power:
-
0.37KW
-
motor:
-
AC Motor
-
Usage:
-
Pumping Water
-
Standard or Nonstandard:
-
Standanrd
-
Pump body:
-
Stainless Steeel
-
Impeller:
-
Brass/PPO/SS304 Impeller
-
MOQ:
-
100 Pcs
-
Fuel:
-
AC Electric Induction Motor
-
Motor:
-
100% Copper Wire
-
Color:
-
Customized Colors
-
Package:
-
1pcs/carton
|
APPLICATION
-
Suitable for use with clean water, or non-aggressive liquids only, without sand or other solid impuritires.
-Suitable for lifting water from well, sprinkling irrigation in garden, pressure boosting of running water, or supporting equipment etc.
|
|
|
|
|
||||
|
OPERATING LIMITS
-
Total suction lift up to 9 mt. with foot valve
-Max. operating pressure: 8 bar. -Max. ambient temperature: +40℃ -Max. liquid temperature: +90℃ -Max. altitude: +1000 mt. |
|
|
MOTOR
-
Insulation class: B
-Protection: IP44 -Speed of rotation: 2850rpm -Continuous duty: S1 |
|
||||
|
DESIGN FEATURES
-
Pump body:Stainless steel AISI304
-motor bracket: cast iron
-Impeller: Brass
-Bearing: C&U -100% copper winding -Built-in thermal protector for single phase motor -Motor shaft: AISI 304 welded shaft -Mechanical seal: Carbon/Ceramic/NBR/SUS304 |
|
|
SPECIAL FEATURES ON REQUEST
-
Anti-rust treatment for casting
-PPO/SUS304 impeller -AISI 1045 motor shaft -Carbon/SiC/V mechanical seal -Other voltage and frequnecy -Insulation class: F |
|
||||
Performance
FAQ
Q
: Are you a factory or trading company?
A
: We are a professional surface water pump manufacturer since 1990, located in Fuan, Fujian, China.
Q
: Do you provide OEM/ODM service?
A
: Yes, we are premium OEM/ODM manufacturer which assessed by independent third parties.
Q
: What is the feature of your products ?
A
: Our products have 3 obviously features: quite, powerful, heavy duty.
Q
: What is your MOQ ?
A
: 100 pcs per model for factory brand and package.
300 pcs per model for OEM brand and package.
Q
: How do you control the quality ?
A
: All production process strict to follow ISO9001 system, QC team check the quality during the production and do the test before each shipment.
Q
: What is your delivery time?
A
: 15 days for sample order, 30 days for container order. ( Busy season may need more days )
