Quick Details
-
Output:
-
Output 1: DC 1.48V 1A*4, Output 2: DC 4.2V/4.35V 2A*2(slot 1&4); 1.5A*3; 1A, Output 3: DC 3.65V 2A*2(slot 1&4); 1.5A*3; 1A*4, Output 4: DC 9V 60mA/120mA*2, 2A*2; 1.5A*3; 1A*4
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Dlyfull
-
Model Number:
-
A4
-
Input:
-
AC 100~240V 50~60Hz 0.8A, DC 12V/3A, AC and DC dual power input;
-
Product name:
-
6 Bays Universal Test Charger
-
Certificate:
-
CE.ROHS.FCC
-
Compatible:
-
Ni-MH, LiFePO4, Li-ion
-
Feature:
-
Charge,Discharge,Test,Refresh
-
Protection:
-
Overcharge, overcurrent, short circuit
-
Warranty:
-
1 Year
Quick Details
-
Type:
-
Charging stand
-
Use:
-
Standard Battery
-
Is LED Lamp Illumination:
-
NO
-
Output:
-
Output 1: DC 1.48V 1A*4, Output 2: DC 4.2V/4.35V 2A*2(slot 1&4); 1.5A*3; 1A, Output 3: DC 3.65V 2A*2(slot 1&4); 1.5A*3; 1A*4, Output 4: DC 9V 60mA/120mA*2, 2A*2; 1.5A*3; 1A*4
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Dlyfull
-
Model Number:
-
A4
-
Input:
-
AC 100~240V 50~60Hz 0.8A, DC 12V/3A, AC and DC dual power input;
-
Product name:
-
6 Bays Universal Test Charger
-
Certificate:
-
CE.ROHS.FCC
-
Compatible:
-
Ni-MH, LiFePO4, Li-ion
-
Feature:
-
Charge,Discharge,Test,Refresh
-
Protection:
-
Overcharge, overcurrent, short circuit
-
Warranty:
-
1 Year
Product Description
SPECIFICATIONS:
|
Product Name
|
6 Bays Universal Test Charger
|
|
Input
|
AC: 100-240V~, 50/60Hz, 0.8A ; DC: 12V/3A
|
|
Output
|
DC 3.65V: 2A*2; 1.5A*3; 1A*4
|
|
|
DC 4.20V: 2A*2; 1.5A*3; 1A*4
|
|
|
DC 4.35V: 2A*2; 1.5A*3; 1A*4
|
|
|
DC 1.48V: 1A*4
|
|
|
DC 9V: 60mA*2; 120mA*2
|
Features:
1. With high-precision single chip microcomputer and high-precision detection circuit, it has precise cut-off voltage, so as to ensure that the battery can be fully charged without overcharging, which is superior to the general industry standard.
2. Large size LCD display, rich display content. It can intuitively display charging current,voltage, capacity, charging or
discharging capacity of battery, internal resistance of battery, time, battery type, etc.
3. The charging current of CH1 and CH4 can up to 2A.
4. Independently charging channel, with reverse polarity protection / short circuit protection / overcharge protection / over
temperature protection and other functions;
5. Comply with:
3.2V LiFePO4, 3.6V/3.7V/3.85V Li-ion:
10340/10440/14500/14650/16340/17335/17500/17670/18350/18500/ 18650/18700/20700/21700/22650/22700/26500/26650/32650；
1.2V Ni-MH/CD:AAAA/AAA/AA/A/SC/C/D
9V Ni-MH/CD//Li-ion/LiFePO4 6F22
6. AC and DC dual power input;
7. It has the functions of charging, discharging, testing, refreshing and internal resistance testing;
8. It has 0V activation function and can activate all kinds of over-discharge lithium-ion batteries;
9. Precise PWM control technology, lithium battery adopts professional three-stage (tc-cc-cv) charging, which is safe and
efficient; nickel hydrogen battery adopts pulse charging, 0 △ V, - △ V function, and has timeout (16h) stop charging and
overcharge voltage protection.
2. Large size LCD display, rich display content. It can intuitively display charging current,voltage, capacity, charging or
discharging capacity of battery, internal resistance of battery, time, battery type, etc.
3. The charging current of CH1 and CH4 can up to 2A.
4. Independently charging channel, with reverse polarity protection / short circuit protection / overcharge protection / over
temperature protection and other functions;
5. Comply with:
3.2V LiFePO4, 3.6V/3.7V/3.85V Li-ion:
10340/10440/14500/14650/16340/17335/17500/17670/18350/18500/ 18650/18700/20700/21700/22650/22700/26500/26650/32650；
1.2V Ni-MH/CD:AAAA/AAA/AA/A/SC/C/D
9V Ni-MH/CD//Li-ion/LiFePO4 6F22
6. AC and DC dual power input;
7. It has the functions of charging, discharging, testing, refreshing and internal resistance testing;
8. It has 0V activation function and can activate all kinds of over-discharge lithium-ion batteries;
9. Precise PWM control technology, lithium battery adopts professional three-stage (tc-cc-cv) charging, which is safe and
efficient; nickel hydrogen battery adopts pulse charging, 0 △ V, - △ V function, and has timeout (16h) stop charging and
overcharge voltage protection.
Details Images
Related Products
Packing&Shipping
1 A4 Charger + 1 AC Cable + 1 User manual + Color Box Package
20pcs/carton
12kg/carton
size: 42*29*36.5CM
