Quick Details
-
Warranty(Year):
-
5-Year
-
Color Rendering Index(Ra):
-
80
-
Lifespan (hours):
-
50000
-
Working Time (hours):
-
50000
-
Product Weight(kg):
-
3
-
Input Voltage(V):
-
AC 100~277V 50-60HZ
-
Lamp Luminous Flux(lm):
-
21000LM
-
Working Temperature(℃):
-
-35 - 65
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Rayborn
-
Model Number:
-
RB-HB-150WU2
-
Input Voltage:
-
AC100~277V emergency high bay ceiling light
-
Luminous Flux:
-
21000LM high bay luminaire
-
LED Chip:
-
SMD3030 high brightness led chips
-
Beam Angle:
-
60/90/120degree smart ufo high bay light
-
Power Factor:
-
>0.98 food industry led high bay light
-
Color Rendering Index:
-
Ra>80 led highbay lights
-
IP Grade:
-
IP65 waterproof dustproof
-
Power:
-
150W high bay led light
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
140
-
Lamp Body Material:
-
Aluminum
-
Application:
-
Warehouse
-
Warranty(Year):
-
5-Year
-
Color Rendering Index(Ra):
-
80
-
Lifespan (hours):
-
50000
-
Working Time (hours):
-
50000
-
Product Weight(kg):
-
3
-
Input Voltage(V):
-
AC 100~277V 50-60HZ
-
Lamp Luminous Flux(lm):
-
21000LM
-
Working Temperature(℃):
-
-35 - 65
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Rayborn
-
Model Number:
-
RB-HB-150WU2
-
Input Voltage:
-
AC100~277V emergency high bay ceiling light
-
Luminous Flux:
-
21000LM high bay luminaire
-
LED Chip:
-
SMD3030 high brightness led chips
-
Beam Angle:
-
60/90/120degree smart ufo high bay light
-
Power Factor:
-
>0.98 food industry led high bay light
-
Color Rendering Index:
-
Ra>80 led highbay lights
-
IP Grade:
-
IP65 waterproof dustproof
-
Power:
-
150W high bay led light
Industrial ufo highbay lighting 100w 200w Square LED High Bay light 150w for warehouse indoor
Industrial LED High Bay Light With 5 Year Warranty (30w-500w )
150W UFO LED HIGH BAY-90D | |||
Item No.: | RB-HB-150WU2 | ||
Input Voltage: | AC 100-277V | ||
Freqency Range: | 50Hz~60Hz | ||
LED Chip: | SMD3030 Chip | ||
Power Driver: | Meanwell HBG | ||
Power Factor: | >0.98 | ||
Power Efficiency: | >92% | ||
Luminous Efficiency: | 140LM/W | ||
LED Power | 150W | ||
LED QTY: | 196pcs 3030SMD | ||
LED Working Voltage: | DC 42~48V | ||
System Consumption: | 153W | ||
LIGHT Luminous Flux | Warm White | 19500LM | |
Pure White | 20500LM | ||
Cool White | 21000LM | ||
Viewing Angle: | 120/90/60 degree | ||
Center Luminance | Height 6M | 228LUX | |
Height 8M | 128LUX | ||
Height 10M | 82LUX | ||
Illuminance Area | Height 6M | Dia.929CM points visible | |
Height 8M | Dia.1239CM points visible | ||
Height 10M | Dia.1549 CM points visible | ||
Illuminance Uniformity: | >0.6 | ||
Color Temperature | Warm White | 3000K~3500K | |
Pure White | 5000K~5700K | ||
Cool White | 6000K~6500K | ||
Color Rendering Index | Ra>80 | ||
Light Distribution: | LED points visible | ||
LED Junction Temperature: | ≤115℃ | ||
Working Temperature: | –40℃~50℃ | ||
IP Grade: | IP65 | ||
Working Life-span: | 50000 H | ||
Power Line: | 1.0 mm three line | ||
Connect Wire | Brown | L | |
Blue | N | ||
Yellow / Green | G | ||
Certificate | CE/ROHS | ||
Size: | 328*H178.5 | ||
Net Weight: | 4.5KG |
Features of
LED High bay Lamp
:
1. UFO design LED High Bay light ,60W/100W/150W/200W all are avaliable ;
2. Lumileds ,OSRAM ,Epistar led chip all are available ;
3. The luminous efficacy of whole lamp can reach 135-160LM/W with high brightness ;
4. LED High bay light are adopted Metal plate pure aluminum heat sink and heat conduction by copper cylinder ;
5. Difference beam angle 60/90/120 degree distribution design as optional ;
6. Reflective rate >90%, CRI is more high,and Lighting is more comfortable ;
7. 304 Stainless steel,high quality, easy install,good rust prevention and durable ;
8. The welding spot high temperature of LED Chip is 70ºC, the high temperature of heat sink is 55 ºC,with excellent heat dissipation capacity and low Light decay ,greatly improves the life of lamps ;
9. Installation ways :rings with chains or other installation accessories ;
10. Waterproof IP65 design ,widely use for indoor and outdoor ,suitable for warehouse ,industrial ,cold storage ,steel workshop etc .
Competitive Advantage of
UFO LED High Bay
:
1. CE & RoHS & TUV&SAA approved, Quality Guaranteed
2. Imported original high brightness LED chip, superior light source
3. OEM & ODM welcome, independent R&D ability, patent design.
4. Fast delivery, 2-15 workdays depends on order quantity after payment confirmed
5. Reliable quality & credit, 5 years warranty and 50.000 hours lifespan
UFO LED High bay light temperature :
All LED lights will be over 24 hours aging tested, inspection department will test 100% products including light up test , power wattage test , highVoltage test , waterproof test , ground connection test and so on,d efective rate is controlled less than 0.1%. Quality is ensured, you can be assured.
1. Workshop and factory lighting.
2. Shopping mall lighting.
3. Museum, stadium and gymnasium lighting.
4. Highway toll station and gas station lighting.
5. Warehouse and smeltery lighting.
Our individual package maximize protecting the LED lights from transfer damage in transit.
1. Label on backside of each LED lights and your required label is available.
2. One piece led Light per carton.
3. This is our regular packing ,if you need,we can custom color packing and put your logo on it.
We has a group of professional technical R & D team, who can provide the OEM / ODM services according to customers and LED lighting solutions,our factory has passed the authentications of ISO9001:2000,CE, FCC, ROSH ,TUV authentication.
Our Services :
As a big led manufacturer with years of experiences,we Rayborn led lghting would very like to be your reliable lighting specialist. We ensure that:
1.Offering you the lowest price with good quality led lights.
2.Delivery the goods to you with speed and precision wherever you are.
3.Reply your inquiry and request in 8 hours during workdays.
4.Keep on researching and developing news prodcuts to satisfy your various needs.
Payment terms :
1. Payment: T/T, L/C at sight, Western Union ,Paypal available
2. Samples can be available within 5-7 working days; Order: 10-20Days
3. Shipping freight is quoted under your requests
4. Shipping port:Shenzhen , China
5. Discounts are offered based on order quantities
