Quick Details
-
Warranty:
-
25 years linear warranty
-
Brand Name:
-
JA Solar
-
Model Number:
-
JAM54S30 400-420/MR
-
Place of Origin:
-
Hebei, China
-
Panel Dimensions:
-
1722*1134*30mm
-
Weight:
-
21.5kg
-
Junction Box:
-
IP 68, 3 Diodes
-
Packaging Configuration:
-
36 Per Pallet
-
Maximum System Voltage:
-
DC 1000V (IEC)
-
Brand:
-
JA Original authentic
-
Cable:
-
4mm2
-
40'HQ:
-
936pcs
-
Certificate:
-
CE/TUV
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, All Black, MBB
-
Panel Efficiency:
-
21%
-
Warranty:
-
25 years linear warranty
-
Brand Name:
-
JA Solar
-
Model Number:
-
JAM54S30 400-420/MR
-
Place of Origin:
-
Hebei, China
-
Panel Dimensions:
-
1722*1134*30mm
-
Weight:
-
21.5kg
-
Junction Box:
-
IP 68, 3 Diodes
-
Packaging Configuration:
-
36 Per Pallet
-
Maximum System Voltage:
-
DC 1000V (IEC)
-
Brand:
-
JA Original authentic
-
Cable:
-
4mm2
-
40'HQ:
-
936pcs
-
Certificate:
-
CE/TUV
Introduction
Nanjing Moge New Energy is Official Authorized Distributor of JA solar.
We are China's Largest Authorized Distributor of Brand Solar Panels:
LONGI SOLAR, CANADIAN
SOLAR
, Jinko solar, TRINA SOLAR, JA SOLAR...
We Supplying Full Range of JA Solar Panels.
I
n
Moregosolar, you can find the best price tier 1 solar panels, so don't waste time and safely buy the best products to start your business on Moregosolar.
Parameter
We Are Official Authorized Distributor of JA Solar.
Supply Full Line of Genuine JA Solar Panels
|
MECHANICAL SPECIFICATION
|
|
|
|
|||
|
Format
|
1722mm x 1134mm x 30mm
|
|
|
|||
|
Weight
|
21.5kg±3%
|
|
|
|||
|
Cell
|
6 x 18 monocrystalline cells
|
|
|
|||
|
Junction Box
|
IP68, 3 diodes
|
|
|
|||
|
Cable
|
Portrait: 300mm(+)/400mm(-); Landscape: 1200mm(+)/1200mm(-)
|
|
|
|||
|
ELECTRICAL CHARACTERISTICS
|
|
|
|
|
|
|||||
|
minimum performance at standard test conditions,stc1 (power tolerance -0~+5w)
|
|
|
|
|
|
|||||
|
Model
|
|
|
JAM72S10 -400/MR
|
JAM72S10 -405/MR
|
JAM72S10 -410/MR
|
|||||
|
Max. Power
|
Pmax
|
[W]
|
400
|
405
|
410
|
|||||
|
Open Circuit Voltage
|
Voc
|
[V]
|
37.07
|
37.23
|
37.32
|
|||||
|
Short Circuit Current
|
Isc
|
[A]
|
13.79
|
13.87
|
13.95
|
|||||
|
Max. Power Voltage
|
Vmp
|
[V]
|
31.01
|
31.21
|
31.45
|
|||||
|
Max. Power Current
|
Imp
|
[A]
|
12.9
|
12.98
|
13.04
|
|||||
|
Efficiency²
|
η
|
[%]
|
20.5
|
20.7
|
21.0
|
|||||
JA solar Genuine
