Quick Details
-
Place of Origin:
-
Kansas, United States
-
Dimension(Long * Breadth * High):
-
6800X2040X2850 mm
-
Machine Weight:
-
3872 kg
-
Bucket capacity:
-
0.1 cbm
-
Product name:
-
Front Wheel Loaders
-
Keyword:
-
Front Loader Tractor
-
Name:
-
Wheel Loader Made
-
Drive type:
-
4 Wheel Drive
-
Engine model:
-
4102turbo
-
Other name:
-
Wheel Backhoe Loader Excavator
-
Function:
-
Multi Purpose Function
-
Max Lifting Force:
-
500kg-850kg
-
Load capacity:
-
1.6 Ton
-
Transmission:
-
Hydrostatic Transmission
Quick Details
-
Engine Brand:
-
Perkins
-
Power:
-
60 KW, 37/42 kW
-
Brand Name:
-
Backhoe JCB
-
Place of Origin:
-
Kansas, United States
-
Dimension(Long * Breadth * High):
-
6800X2040X2850 mm
-
Machine Weight:
-
3872 kg
-
Bucket capacity:
-
0.1 cbm
-
Product name:
-
Front Wheel Loaders
-
Keyword:
-
Front Loader Tractor
-
Name:
-
Wheel Loader Made
-
Drive type:
-
4 Wheel Drive
-
Engine model:
-
4102turbo
-
Other name:
-
Wheel Backhoe Loader Excavator
-
Function:
-
Multi Purpose Function
-
Max Lifting Force:
-
500kg-850kg
-
Load capacity:
-
1.6 Ton
-
Transmission:
-
Hydrostatic Transmission
-
420 07A BACKHOE LOADER CFG2
-
AIR CONDITIONER, T4F
-
AUTO-UP STABILIZERS
-
BATTERY, HEAVY DUTY
-
BELT, SEAT, 2" SUSPENSION
-
BUCKET-HD, 24", 6.2 CFT
-
BUCKET-MP, 1.3 CYD
-
CAB, DELUXE
-
COUNTERWEIGHT, 1070 LBS
-
CUTTING EDGE, TWO PIECE
-
DISPLAY, STANDARD
-
Engine
-
BACKHOE HAS AN EXTEND A HOE WITH 24" BUCKET WITH FIVE DIGGING TEETH
-
HAS TWO LEVER OPERATION
-
RUBBER BASE STABILIZERS
-
HAS A NEW INJECTION PUMP
-
NEW STARTER
-
NEW FUEL PUMP
-
REAR END JUST SPENT ON IT
-
ALSO SPENT NEW CAB FLOOR
-
CAB HAS THREE WINDOWS THAT ARE CRACKED
-
NEEDS THE SIDE SHIELD FOR THE MOTOR
-
GOOD OPERATING COND
| The Main Performance Parameter of Backhoe Loader ASG388 | |||
| Overall Operating Weight | 8200KG | Final Reducer | Single Stage Final Reducer |
| Transport Dimension | Rated Loader of Axle | 8/18.5t | |
| mm L*W*H | 5920×2250×3770 | Transmission System | |
| Wheel base | 2200mm | Torque Converter | |
| Min. Ground Clearance | 300mm | Model | YJ280 |
| Bucket Capacity | 1.0m 3 | Type | Single-stage Three Elements |
| Breakout Force | 38KN | Max. Efficiency | 84.4% |
| Loading Lifting Capacity | 2500KG | Inlet Pressure | 0.5Mpa |
| Bucket Dumping Height | 2742mm | Outlet Pressure | 1.1Mpa-1.3 Mpa |
| Bucket Dumping Distance | 925mm | Cooling Method | Oil-cooling Pressure Circulation |
| Digging Depth | 52mm | Gearbox | |
| Backhoe Capacity | 0.3 m 3 | Type | Fixed Shaft Power Transmission |
| Max. Digging Depth | 4082/4500mm | Oil Pressure of Clutch | 1373Kpa-1569 Kpa |
| Swing Angle of Excavator Grab | 190 o | Gears | Two Gears Ahead, Two Gears Astern |
| Max. Pulling Force | 39KN | Max.Speed | 28Km/h |
| Engine | Tyre | ||
| Model | YC4A105Z-T20 | Model | 14-17.5/19.5L-24 |
| Type | In Line Direct injection Four-Stroke and Injection Combustion Chamber | Pressure of Front wheel | 0.55Mpa |
| Cylinder-Inside Diameter*Stroke | 4-102×120 | Pressure of Back Wheel | 0.223Mpa |
| Rated Power | 75KW | Brake System | |
| Rated Speed | 2200r/min | Service Brake | Air Over Oil Caliper Brake |
| Min. Fuel Consumption | ≤242g/km.h | External Type | |
| Max.Torque | ≥410N.M | Self-regulation | |
| Displacement | 4.4L | Self-balance | |
| Steering System | Emergency Brake | Operation Power Implementing brake | |
| Model of Steering Device | BZZ5-250 | Manual Operation Power Terminating Brake | |
| Steering Angle | ±36 o | Hydraulic System | |
| Min. turning radius | 6581mm | Digging Power of Excavator Grab | 46.5KN |
| Pressure of the system | 12Mpa | Digging Power of Dipper | 31KN |
| Axle | Bucket Lifting Time | 6.8S | |
| Manufacturer | Rear axle: Feicheng Axle Factory | Bucket Lowering Time | 3.1S |
| Main Transmission Type | Double Reduction | Bucket Discharge Time | 2.0S |
