Quick Details
-
Max. Spindle Speed (r.p.m):
-
1500 r.p.m
-
Spindle Bore(mm):
-
92
-
Width of bed (mm):
-
720 mm
-
Spindle Motor Power(kW):
-
22/30
-
Max. Turned Length (mm):
-
540
-
Travel (X Axis)(mm):
-
260 mm
-
Travel (Z Axis)(mm):
-
580 mm
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
2400*2000*2150
-
Model Number:
-
CT4050
-
Voltage:
-
220/380
-
Weight (KG):
-
5000
-
Marketing Type:
-
Hot Product 2024
-
Max Bed turning diameter:
-
650
-
Max turning diameter of slide plate:
-
500
-
Maxturning length:
-
540
-
Max.stroke X Direction:
-
260
-
Max.stroke Z Direction:
-
580
-
Spindle speed:
-
1500
-
Main motor power:
-
22/30
-
Spindle head type:
-
A2-8
-
Diameter of spindle through hole:
-
92
Quick Details
-
Type:
-
Horizontal
-
Max. Length of Workpiece (mm):
-
540
-
Year:
-
2024
-
Max. Spindle Speed (r.p.m):
-
1500 r.p.m
-
Spindle Bore(mm):
-
92
-
Width of bed (mm):
-
720 mm
-
Spindle Motor Power(kW):
-
22/30
-
Max. Turned Length (mm):
-
540
-
Travel (X Axis)(mm):
-
260 mm
-
Travel (Z Axis)(mm):
-
580 mm
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
2400*2000*2150
-
Model Number:
-
CT4050
-
Voltage:
-
220/380
-
Weight (KG):
-
5000
-
Marketing Type:
-
Hot Product 2024
-
Max Bed turning diameter:
-
650
-
Max turning diameter of slide plate:
-
500
-
Maxturning length:
-
540
-
Max.stroke X Direction:
-
260
-
Max.stroke Z Direction:
-
580
-
Spindle speed:
-
1500
-
Main motor power:
-
22/30
-
Spindle head type:
-
A2-8
-
Diameter of spindle through hole:
-
92
Products Description
|
Model
|
Unit
|
CT4050
|
|
Standard chuck specifications
|
inch
|
12(standard)
15(optional) |
|
Max Bed turning diameter
|
mm
|
Ф650
|
|
Max turning diameter of slide plate
|
mm
|
Ф500
|
|
Max turning diameter
|
mm
|
/
|
|
Maxturning length
|
mm
|
540
|
|
Max.stroke X Direction
|
mm
|
260
|
|
Max.stroke Z Direction
|
mm
|
580
|
|
Spindle speed range
|
r/min
|
1500
|
|
Main motor power
|
kw
|
22/30
|
|
Spindle head type
|
|
A2-8
|
|
Diameter of spindle through hole
|
mm
|
Ф92
|
|
Diameter of passable bar
|
mm
|
Ф74
|
|
Diameter dimension of spindle frontaxle
|
mm
|
Ф140
|
|
Fast Feeding Speed X Direction
|
m/min
|
20
|
|
Fast Feeding Speed Z Direction
|
m/min
|
15
|
|
ATC Drivingmode
|
|
Hydraulic+Servo
|
|
Number oftool bits
|
pcs
|
8/12
|
|
Single station transposition time
|
s
|
0.5
|
|
Round cutter square size
|
mm
|
25*25
|
|
Boring rod diameter
|
mm
|
Ф40
|
|
Shape size (LxWxH)
|
mm
|
2400*2000*2150
|
|
Machine toolweight
|
kg
|
5000
|
Servo Turret
High positioning accuracy with servo motor drive
CNC system
CNC system standard with new SYNTEC system,
optional Siemens, Fanuc, Mitsubishi
Guides & Screws
Guides and screws are from Taiwan HIWIN, PMI and NACHI
Structural Designs
Maximizes tip stiffness, minimizes vibration and improves stability
Lubricating System
Fuel supply is computerized for greater precision
Intelligent Manufacturing
We offer complete line solutions
