Quick Details
-
Weight (KG):
-
800 KG
-
Power (kW):
-
7.5
-
Name:
-
Wood Pallet Dismantling Machine
-
Application:
-
all place
-
Usage:
-
Metal Cutting
-
After-sales Service Provided:
-
Online Support
-
Voltage:
-
380V/50HZ/3PH
-
Table width:
-
1700mm
-
Table length:
-
1200mm
-
Cutting thickness:
-
5mm-150mm
-
Saw wheel diameter:
-
600mm
-
Capacity:
-
40-60 Pallets/Minute
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
AG Mach
-
Machine Type:
-
Horizontal
-
Weight (KG):
-
800 KG
-
Power (kW):
-
7.5
-
Name:
-
Wood Pallet Dismantling Machine
-
Application:
-
all place
-
Usage:
-
Metal Cutting
-
After-sales Service Provided:
-
Online Support
-
Voltage:
-
380V/50HZ/3PH
-
Table width:
-
1700mm
-
Table length:
-
1200mm
-
Cutting thickness:
-
5mm-150mm
-
Saw wheel diameter:
-
600mm
-
Capacity:
-
40-60 Pallets/Minute
Industrial Pallet Recycling Machines Sawmill Wood Pallet Splitting Machine
Specification
|
Model
|
AG-TP1400
|
|
Table length
|
1700MM
|
|
Table width
|
1400mm
|
|
Cutting Thickness
|
5-150MM
|
|
Saw Wheel Diameter
|
600MM
|
|
Motor Power, 3PHASE
|
7.5KW, voltage as customer needs
|
|
Pallet Dismantling Capacity
|
40-60/Minute
|
|
Nail Cutting Saw Blade
|
6850x41x1.30mm
|
|
Weight
|
800KG
|
|
Overall Size
|
3300x1500x1400mm
|
Product Description
Product Introduction:
This machine is designed for a full range of pallet recycling including pallet prep, repair, dismantle, and recovery. Due to the unique combination of high torque and low RPMs, the pallet dismantler has an expected blade life of 1,000 to 1,500 dismantled pallets per blade which is nearly double the blade life of competitive pallet dismantling saws.
Main Features of wood pallet dismantler saw:
1. Pallet Dismantling Sawmill is mainly used wooden pallets segmentation,
2. Quickly and efficiently,
3. Saving labor
4. Easy operation and long use life.
Advantage:
1.This machine is designed for one or two operators.
2.This machinefeatures a sturdy welded steel tube frame that firmly supports two pneumatic wheels.
3.The bi-metal blade that cuts the nails to dismantle the pallet is powered by a 7.5kw electric motor with a gear reduction drive.
4.A pneumatic table lift has preset heights to enable quick and convenient shifting between upper and lower cut points to easily remove stringer boards, blocks, and deck boards of a pallet.
Detailed Pics
Place And Pass Pallets
Turn the wheel and tighten the saw blade
Control Button
UP and Down Adjusted Platform
the platform can adjust the height .we can according the the thickness of wood pallet adjusted the platform up and down .
Foot Pedal
the foot pedal use for control the adjustable platform up and down according to the thickness of the wood pallet .
USA Band Saw Blade
The band saw blades are specially designed for cutting metal nails
Slope Platform
the sloping table is Slope platform design is beneficial to board slip and collection
Final Products
