Quick Details
-
Application:
-
ATV
-
Other name:
-
Dune buggy
-
Engine Displacement:
-
300cc
-
MAX SPEED:
-
75km/h
-
Wheel size:
-
24x8-12/23x10-12
-
Max power:
-
17kw
-
MAX LOAD:
-
250kgs
-
Start mode:
-
Electric Button Start
-
Fuel Tank Capacity:
-
35L
-
Certification:
-
EPA /CARB / CE
Quick Details
-
Displacement:
-
>300cc
-
Brand Name:
-
Funrun
-
Place of Origin:
-
Zhejiang, China
-
Application:
-
ATV
-
Other name:
-
Dune buggy
-
Engine Displacement:
-
300cc
-
MAX SPEED:
-
75km/h
-
Wheel size:
-
24x8-12/23x10-12
-
Max power:
-
17kw
-
MAX LOAD:
-
250kgs
-
Start mode:
-
Electric Button Start
-
Fuel Tank Capacity:
-
35L
-
Certification:
-
EPA /CARB / CE
Specifications
1,Engine
Engine type: 4-stroke Single cyclinder
Displacement: 278cc
Max power: 18HP/6500rpm
Max torque: 22Nm/5000rpm
Fuel system: Carbureted
Cooling: water-cooled
Starter: Electric starter
2,Drive Train
Transmission: CVT with F/N/R
Final drive: Chain/ Rear wheel drive
suspension: Front Dual-A arm independent
Rear 3-links independent
Brake:Front&Rear 4-wheel hydrauilc disc
Tire&wheels: Front 24*8-12 & 12*6Aluminium rim
Rear 23*10.5-12 & 12*9Aluminium rim
3,Dimensions
Overall size:2620*1650*1620cm
Wheelbase: 194cm
Dry weight: 320KG
Ground clearance: 30cm
4,Capacities
Fuel capacity: 35L
Seat: 2 Seat
Max speed:60Km/h
5,package size:232*165*88cm
6,Loading Qty:6PCS/20"GP
14PCS/40"GP
21PCS/40"HQ
Established in 2016, JINHUA FUNRUN VEHICLE TECHNOLOGY CO., LTD is a manufacturer specialized in the research, development and production of Go-Kart, ATV and Off road Mini bike. We are located in Jinhua city, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world.
1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the
goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.
