> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 years, 25 Years Output Power Guarantee
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM355P-72
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1956*992*40mm
-
Solar cell:
-
Poly 156x156mm
-
Certificate:
-
TUV
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP65 Rated
-
Color:
-
Blue Ad Black
-
Front Cover:
-
3.2mm High transmission, low Iron
-
OEM Order:
-
Acceptable
-
Application:
-
Solar Home System
Quick Details
-
Cell size:
-
156.75mmx156.75mm
-
Type:
-
PERC
-
Panel Efficiency:
-
20%
-
Warranty:
-
25 years, 25 Years Output Power Guarantee
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM355P-72
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1956*992*40mm
-
Solar cell:
-
Poly 156x156mm
-
Certificate:
-
TUV
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP65 Rated
-
Color:
-
Blue Ad Black
-
Front Cover:
-
3.2mm High transmission, low Iron
-
OEM Order:
-
Acceptable
-
Application:
-
Solar Home System
Product Description
|
Moduel
|
BSM325P-72
|
BSM330P-72
|
BSM335P-72
|
BSM340P-72
|
BSM350P-72
|
||||
|
Rated Maximum Power at STC
|
325W
|
330W
|
335W
|
340W
|
350W
|
||||
|
Open CircuitVoltage(Voc/V)
|
46.0
|
46.1
|
46.3
|
46.5
|
46.9
|
||||
|
Maximum Power Voltage(Vmp/V)
|
37.17
|
37.6
|
37.9
|
38.2
|
38.5
|
||||
|
Short Circuit Current(Isc/A)
|
9.05
|
9.28
|
9.36
|
9.45
|
9.6
|
||||
|
Maximum Power Current(Imp/A)
|
8.74
|
8.78
|
8.84
|
8.9
|
9.09
|
||||
|
Module Efficiency(%)
|
16.77
|
17.00
|
17.3
|
17.5
|
18.0
|
||||
|
Power Tolerance
|
-0~+5W
|
|
|
|
|
||||
|
Standard Test Condition(STC)
|
Irradiance 1000W/m2,Cell Temperature 25℃,Air Mass1.5
|
|
|
|
|
||||
Detailed
Glass
Solar Cell
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
Frame
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip designglue injection
Junction box
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
Packing & Delivery
|
By Sea
|
Delivery from Shanghai or Ningbo seaport
|
|
|
||
|
By Air
|
Departure from Shanghai Pudong Airport
|
|
|
||
|
By Express
|
By TNT/DHL
|
|
|
||
Our Company
History .
From 1983, first for silicon business , 2004 beginning produce solar cell ,solar panel . capacity 50MW per year
Capacity .
Full automatic production line ,all machine import from Germany . now capacity 500MW per year
International .
400MW export to more than 80 counties , EPC company in Germany ,Italy ,USA and Canada ,
World Partner.
More than 20 famous international famous company partner in the world , solar city,Solar world ,Q-Cell ,Tesla ...
Office&Warehouse.
more than 4 office in the world ,Germany ,USA ,Brasil ,Canada,Ukraine
Los Angeles& Rotterdam warehouse
Service .
100 international sales, English,Spain,France Language . we support all time all language service.
Project
250KW on grid solar project in Malta,EU
60KW on grid solar project in Guatemala,South America
1.2MW solar power plant in Ecuador,South America
144KW on grid solar project in California,USA
150KW on grid solar project in Japan
