Quick Details
-
Application:
-
engineering
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
xiuhe
-
Model Number:
-
75-900
-
Color:
-
Black
-
Material:
-
HDPE
-
Height:
-
50mm
-
Thickness:
-
1.0mm
-
Weld distance:
-
900mm
-
Description:
-
Textured Perforated Geocell Product
-
Surface:
-
Steep Slope Protection Reinforcement
-
Application of geocell:
-
Road Slope Reinforcement
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
-
Application:
-
engineering
-
Design Style:
-
Industrial
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
xiuhe
-
Model Number:
-
75-900
-
Color:
-
Black
-
Material:
-
HDPE
-
Height:
-
50mm
-
Thickness:
-
1.0mm
-
Weld distance:
-
900mm
-
Description:
-
Textured Perforated Geocell Product
-
Surface:
-
Steep Slope Protection Reinforcement
-
Application of geocell:
-
Road Slope Reinforcement
Product Description
HDPE Geocell
Geocell is a net-shapped cell structure made by welding high intensity thermoplastic sheet.
Smooth & Non-perforated HDPE Geocell
Textured & Non-perforated HDPE Geocell
Smooth & Perforated HDPE Geocell
Textured & Perforated HDPE Geocell
Features
It is flexible to fold during transportation,stretching out and being filled with stone or concrete during service,and forming into structure with powerf.
Application
1.Geocell can be used as cushion coat to shrengthen loading capacity of weak ground.
2.Geocell can be paved in slope as slope protection structure.
3.Geocell can be used to build the support block structure.
Geocell can be used as cushion coat
Geocell can be paved in slope
Bulid the support block structure
HDPE Geocell Product Properties
|
Spec
|
Height
(mm)
|
Welding distance
(mm)
|
Sheet thickness(mm)
|
|
Seam peel
strength≥（N）
|
Expanded cell size(mm)
|
Expanded panel size(m)
|
|
|
|
|
|
smooth
|
textured
|
|
|
|
|
|
TGLG-75-330
|
75
|
330
|
1.1
|
1.5
|
1065
|
244*203
|
2.44*6.15
|
|
|
TGLG-100-330
|
100
|
|
1.1
|
1.5
|
1420
|
|
|
|
|
TGLG-150-330
|
150
|
|
1.1
|
1.5
|
2130
|
|
|
|
|
TGLG-200-330
|
200
|
|
1.1
|
1.5
|
2840
|
|
|
|
|
TGLG-75-356
|
75
|
1.1356
|
1.1
|
1.5
|
1065
|
259*224
|
2.56*6.52
|
|
|
TGLG-100-356
|
100
|
|
1.1
|
1.5
|
1420
|
|
|
|
|
TGLG-150-356
|
150
|
|
1.1
|
1.5
|
2130
|
|
|
|
|
TGLG-200-356
|
200
|
|
1.1
|
1.5
|
2840
|
|
|
|
|
TGLG-75-400
|
75
|
400
|
1.1
|
10651.5
|
1065
|
295*250
|
4*5
|
|
|
TGLG-100-400
|
100
|
|
1.1
|
1.5
|
1420
|
|
|
|
|
TGLG-150-400
|
150
|
|
1.1
|
1.5
|
2130
|
|
|
|
|
TGLG-200-400
|
200
|
|
1.1
|
1.5
|
2840
|
|
|
|
|
TGLG-75-445
|
75
|
445
|
1.1
|
1.5
|
1065
|
320*287
|
2.56*8.35
|
|
|
TGLG-100-445
|
100
|
|
1.1
|
1.5
|
1420
|
|
|
|
|
TGLG-150-445
|
150
|
|
1.1
|
1.5
|
2130
|
|
|
|
|
TGLG-200-445
|
200
|
|
1.1
|
1.5
|
2840
|
|
|
|
|
TGLG-75-660
|
75
|
660
|
1.1
|
1.5
|
1065
|
488*406
|
2.44*12.29
|
|
|
TGLG-100-660
|
100
|
|
1.1
|
1.5
|
1420
|
|
|
|
|
TGLG-150-660
|
150
|
|
1.1
|
1.5
|
2130
|
|
|
|
|
TGLG-200-660
|
200
|
|
1.1
|
1.5
|
2840
|
|
|
|
|
TGLG-75-712
|
75
|
712
|
1.1
|
1.5
|
1065
|
508*475
|
2.56*13.72
|
|
|
TGLG-100-712
|
100
|
|
1.1
|
1.5
|
1420
|
|
|
|
|
TGLG-150-712
|
150
|
|
1.1
|
1.5
|
2130
|
|
|
|
|
TGLG-200-712
|
200
|
|
1.1
|
1.5
|
2840
|
|
|
|
Plastic connector and hook for connecting geocell.
Produntion Display
Company Introduction
Shandong XiuHe Engineering Materials Co., Ltd., established in 2018, is a leading manufacturer and supplier of geosynthetics materials in China. We have over 40 professional advanced production lines with an annual production capacity of more than 300 million square meters, which enables our company to deliver fast to our customers.
Our products include geomembrane, geogrid, geotextile, geocell, geonet, drainage net, drainage board, erosion control geomat, BOP stretched net, safety fence, geocomposite, weed mat, geobags, geotubes, etc. These products are mainly used in the foundation construction such as roadways, railways, airports, mines, irrigation works, electric power, water and land protection, environment greening, etc.
Our products include geomembrane, geogrid, geotextile, geocell, geonet, drainage net, drainage board, erosion control geomat, BOP stretched net, safety fence, geocomposite, weed mat, geobags, geotubes, etc. These products are mainly used in the foundation construction such as roadways, railways, airports, mines, irrigation works, electric power, water and land protection, environment greening, etc.
Shandong XiuHe Engineering Materials Co., Ltd. has established advanced laboratories for internal quality control.
We built strict quality control system of whole processes from raw materials testing, production process, to final products
testing. And we always improve our production technology in order to provide high quality products to our customers. We has got certificates such as ISO9001、 ISO14001、ISO45001. As a famous brand, our products have been exported to more than 30 countries and areas all over the world and get high reputation from customers. We always warmly invite more customers and friends to be our business partners. We look forward to cooperating with you !
We built strict quality control system of whole processes from raw materials testing, production process, to final products
testing. And we always improve our production technology in order to provide high quality products to our customers. We has got certificates such as ISO9001、 ISO14001、ISO45001. As a famous brand, our products have been exported to more than 30 countries and areas all over the world and get high reputation from customers. We always warmly invite more customers and friends to be our business partners. We look forward to cooperating with you !
Packaging & Shipping
Packaging:
Strips packaging or Pallet Packaging
Lead time:
Winthin 10-15 days after receiving the deposit payment
Producing capacity: Two 40FCL per week
Producing capacity: Two 40FCL per week
