1.Safe A+ lithium iron phosphate battery
2.Each battery pack is equipped with a smart BMS with built-in overload and overcharge
protection
3.Compared with traditional modules, it can meet the capacity storage and greatly
improve the cycle life
4.The weight is about 70% lighter than that of lead-acid batteries
5. Up to 4 can be connected in series or in parallel
6.OEM/ODM:voltage/capacity/size/connector/display/color/logo/sticker etc.
7.Ideal for ships, RVs, sweepers, golf, UPS systems, solar storage, solar, off grid, etc.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
SZKMW
-
Model Number:
-
kmw-Multiple models
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
31kg
-
The discharge rate:
-
200A, Max 400A(<3S)
-
Battery type:
-
Lithium Iron Phosphate Battery
-
battery size:
-
522x240x244mm
-
Continuous current:
-
200A
-
Overcharge cut-off voltage:
-
14.6V
-
Over discharge voltage:
-
10V
-
Charging method:
-
CC/CV
-
Max charge current:
-
0.5C
-
Cycle life:
-
4000 Cycles
-
Protection:
-
Built-in Smart BMS
Quick Details
-
Storage Type:
-
-10 ~ 50°C
-
Anode Material:
-
LFP
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
SZKMW
-
Model Number:
-
kmw-Multiple models
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
31kg
-
The discharge rate:
-
200A, Max 400A(<3S)
-
Battery type:
-
Lithium Iron Phosphate Battery
-
battery size:
-
522x240x244mm
-
Continuous current:
-
200A
-
Overcharge cut-off voltage:
-
14.6V
-
Over discharge voltage:
-
10V
-
Charging method:
-
CC/CV
-
Max charge current:
-
0.5C
-
Cycle life:
-
4000 Cycles
-
Protection:
-
Built-in Smart BMS
Product Description
Note:
12v100Ah, 12v240Ah . stock in German warehouse and American warehouse, and can be shipped quickly, other models need to be shipped from China.
contact immediately
Features
Specification
|
Nominal voltage
|
12.8v
|
25.6v
|
|
|
Nominal capacity
|
100ah
|
100ah
|
|
|
Battery type
|
grade A 3.2VLifePO4 Prismatic 4S
|
grade A 3.2V LifePO4 Prismatic 8S
|
|
|
Charge Voltage
|
14.6V±0.2V
|
29.2V±0.2V
|
|
|
Discharge Cut-off Voltage
|
10V
|
20V
|
|
|
Max charging current (A)
|
50A(0.5C)
|
|
|
|
BMS function
|
Overcharge, overdischarge, overcurrent, short circuit, etc.
|
|
|
|
Continuous discharge current
|
120A
|
|
|
|
Peak current
|
240A (<3s)
|
|
|
|
charging temperature
|
0℃ to 55℃ (32F to 131F) @60±25% Relative Humidity
|
|
|
|
discharge temperature
|
-20℃ to 60℃ (-4F to 140F) @60±25% Relative Humidity
|
|
|
|
Storage Temperature
|
-20℃ to 45℃ (-4F to 113F) @60±25% Relative Humidity
|
|
|
|
Life cycle
|
It is 3000 times at 85% dose, 5000 times at 65% dose, and 8000 times at 40% dose.
|
|
|
|
Net weight
|
13kg
|
23kg
|
|
|
Battery display
|
The conventional ABS housing has a display screen. Others can be customized
|
|
|
|
Battery size
|
330*172*215mm
(customizable) |
530*235*200mm
(customizable) |
|
|
Case material
|
ABS
|
|
|
|
Terminal Type
|
M8 (customizable)
|
|
|
|
Warranty
|
5 years
|
|
|
