Quick Details
-
Range of Spindle Speed(r.p.m):
-
64 - 1500 r.p.m
-
Max. Turned Length (mm):
-
510 mm
-
Place of Origin:
-
Liaoning, China
-
Weight (KG):
-
382 KG
-
Marketing Type:
-
Other
-
After-sales Service Provided:
-
Online support,Video technical support
-
Local Service Location:
-
None
Quick Details
-
Max. Length of Workpiece (mm):
-
530 mm
-
Machining Capacity:
-
Light Duty
-
Spindle Bore(mm):
-
38 mm
-
Range of Spindle Speed(r.p.m):
-
64 - 1500 r.p.m
-
Max. Turned Length (mm):
-
510 mm
-
Place of Origin:
-
Liaoning, China
-
Weight (KG):
-
382 KG
-
Marketing Type:
-
Other
-
After-sales Service Provided:
-
Online support,Video technical support
-
Local Service Location:
-
None
|
ITEM
|
|
CZ1224G
|
|
CZ1324G
|
|
||
|
|
|
Norton lever
|
Closed box
|
Norton lever
|
Closed box
|
||
|
Swing over bed
|
mm
|
φ305
|
|
φ330
|
|
||
|
Swing over carriage
|
mm
|
φ173
|
|
φ195
|
|
||
|
Swing over gap
|
mm
|
φ440
|
|
φ465
|
|
||
|
Width of bed-way
|
mm
|
182
|
|
182
|
|
||
|
Distance between centers
|
mm
|
530
|
|
530
|
|
||
|
Spindle taper
|
|
M.T.5
|
|
M.T.5
|
|
||
|
Spindle bore
|
mm
|
φ38
|
|
φ38
|
|
||
|
Step of speed
|
|
9
|
|
9
|
|
||
|
Range of speed
|
rpm
|
64~1500
|
|
64~1500
|
|
||
|
Metric thread
|
|
15kinds (0.25~7.5mm)
|
11kinds (0. 5~3.5mm)
|
15kinds (0.25~7.5mm)
|
11kinds (0. 5~3.5mm)
|
||
|
Inch thread
|
|
40kinds(4~112T.P.I)
|
14kinds(7-1/2~48T.P.I)
|
40kinds(4~112T.P.I)
|
14kinds(7-1/2~48T.P.I)
|
||
|
Range of feed amount
|
mm/r
|
0.12~0.42(0.0047”~0.0165)
|
0.051~0.303(0.002”~0.012”)
|
0.12~0.42(0.0047”~0.0165)
|
0.051~0.303(0.002”~0.012”)
|
||
|
Diameter of lead screw
|
mm
|
φ22(7/8”)
|
|
φ22(7/8”)
|
|
||
|
Pitch of lead screw
|
|
3mm or 8T.P.I
|
|
3mm or 8T.P.I
|
|
||
|
Saddle travel
|
mm
|
510
|
|
510
|
|
||
|
Cross travel
|
mm
|
150
|
|
150
|
|
||
|
Compound travel
|
mm
|
90
|
|
90
|
|
||
|
Barrel travel
|
mm
|
100
|
|
100
|
|
||
|
Barrel diameter
|
mm
|
φ32
|
|
φ32
|
|
||
|
Taper of center
|
mm
|
M.T.3
|
|
M.T.3
|
|
||
|
Motor power
|
Kw
|
1.1(1.5HP)
|
|
1.1(1.5HP)
|
|
||
|
Motor for coolant system’s power
|
Kw
|
0.04(0.055HP)
|
|
0.04(0.055HP)
|
|
||
|
Machine(L×W×H)
|
mm
|
1420×750×760
|
|
1420×750×760
|
|
||
|
Stand(left) (L×W×H)
|
mm
|
400×370×700
|
|
400×370×700
|
|
||
|
Stand(right) (L×W×H)
|
mm
|
300×370×700
|
|
300×370×700
|
|
||
|
Machine
|
Kg
|
380/430
|
|
380/430
|
|
||
|
Stand
|
Kg
|
60/65
|
|
60/65
|
|
||
|
Loading amount
|
|
27pcs/20’container
|
|
27pcs/20’container
|
|
||
