Quick Details
-
Weight:
-
2599 KG
-
Clutch:
-
Dual- Stage Clutch
-
Engine:
-
4 Cylinder Diesel Engine
-
Engine type:
-
4 Cylinder Engine
-
Horse power:
-
20hp~90hp
Quick Details
-
Brand Name:
-
KUBOTA
-
Year:
-
2019
-
Place of Origin:
-
Austria
-
Weight:
-
2599 KG
-
Clutch:
-
Dual- Stage Clutch
-
Engine:
-
4 Cylinder Diesel Engine
-
Engine type:
-
4 Cylinder Engine
-
Horse power:
-
20hp~90hp
crawler tractor
1).OVERALL UNIT
Transmission box: special steel casting transmission
Main dimension(mm): L 2200 x W 970x H 1120
Wheelbase:(mm) 1150
Wheel tread:
front wheel(mm) 850
Rear-wheel(mm) 800
Mini-ground clearance(transmission bottom) (mm) 200
Mini-turning circus radius:(m) 2
Structural weight:(kg) 420
Theoretical speed: km/h
First gear 2.24
second gear 3.48
third gear 5.62
First reverse gear 1.72
Second reverse gear 6.97
2) ENGINE MAIN SPECIFICATION
Engine model: R190 JDZ195
Engine type: horizontal, single cylinder, four stroke
Rated turning speed: r/min 2400
Rated power: HP 10HP 12.5HP
Cooling type: evaporative cooling, condense
3).DRIVE SYSTEM
1.clutch dry type, double , normally jointing and fricting type.
Final drive: single stage spur gear transmission
3.differential: support conical planetary gear reducer
4.transmission: (3+1)*2 cylinder gear drive
5.brake: external shoe type brake
6.drive type between engine and clutch: triangle belt
7.drive type between PTO and hydraulic pump :V-belt
4).TRAVEL AND TURNING SYSTEM
Front axle: adjustable separating type
Tyre type: front wheel 4.00-8/4.0-12
Rear-wheel 6.00-12/6.5-16
Tyre pressure:
Front wheel: 600kpa
Rear-wheel: 250kpa
Steering gear: worming gear type
Toe-in of front wheel(mm): 4~8
Front-wheel camber: 2 0 ±30 ’
king pin inclination: 7 0 ±15 ’
kingpin caster: 3 0 ±15 ’
5.WORKING DEVICE:
Lifting mechanism:
(1) manual(lever lifting, ratchet holding.)
(2)hydraulic lifting
(3)Type:split pump : CBN-E304 gear pump
Safety valve setting pressure(mpa): 16
lifting time(s): ≤2
PTO:
1.type:sidely placed dependent type
2.turning speed :r/min: 1378
3.turning direction: clockwise
6).ELECTRICAL DEVICES
Generator type: YONGCI-branded flywheel generator 12V 250W
Front headlight: 12V 40W/100W
Indicator: 12V 20W
Double gear switch: JK107
7).MAIN FILLING QUANTITY
Hydraulic tank: L 1.5
| horsepower | 10 | 12 | 15 | 18 | 20 |
| engine | (Z)190N | CF13N | CZ1105 | CZ1110 | CJ1115 |
| Shift | 2wd 6+2 | 2wd 6+2 | 2wd 6+2 | 2wd 6+2 | 2wd 6+2 |
| wheel | 4.0-12 6.5-16 | 4.0-12 6.5-16 | 4.0-12 6.5-16 | 4.0-12 6.5-16 | 4.0-12 6.5-16 |
| mechanical | steering | steering | steering | steering | steering |
