Quick Details
-
Brand Name:
-
Olycom
-
Use:
-
CCTV surveillance
-
Product name:
-
8 port unmanaged POE switch
-
Transmission Rate:
-
10/100M
-
Dimensions (H x W x D):
-
220mm*140mm*45mm
-
Warranty:
-
12 month
-
Application:
-
CCTV Systems
-
Certificate:
-
CE RoHS FCC ISO9001
-
Power Supply:
-
48V
-
PoE Standard:
-
IEEE802.3af/at
-
Brand:
-
Support OEM
-
Weight:
-
1.05kg
Quick Details
-
Type:
-
Enterprise Switch
-
Model Number:
-
OM011008-PSE-FE
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Olycom
-
Use:
-
CCTV surveillance
-
Product name:
-
8 port unmanaged POE switch
-
Transmission Rate:
-
10/100M
-
Dimensions (H x W x D):
-
220mm*140mm*45mm
-
Warranty:
-
12 month
-
Application:
-
CCTV Systems
-
Certificate:
-
CE RoHS FCC ISO9001
-
Power Supply:
-
48V
-
PoE Standard:
-
IEEE802.3af/at
-
Brand:
-
Support OEM
-
Weight:
-
1.05kg
Product Description
8*10/ 100Mbps PoE ports, 2*10/ 100/1000Mbps network ports, 1*1000M SFP fiber port
Support IEEE802.3af/at
Support restrain network storm, VLAN function
Support Max Transmission distance up to 250m
All port supported by MDI/ MDIX auto flip and self-negotiation
Built-in power supply
Maximum power of single PoE port : 30 W
Whole machine power: 120W&150W
Adopts store-and-forward architecture
Support IEEE802.3af/at
Support restrain network storm, VLAN function
Support Max Transmission distance up to 250m
All port supported by MDI/ MDIX auto flip and self-negotiation
Built-in power supply
Maximum power of single PoE port : 30 W
Whole machine power: 120W&150W
Adopts store-and-forward architecture
Fan-less, natural cooling, small,compact and quiet design,suitable for desktop or wall
Support lightning protection 4kV
Support lightning protection 4kV
Specification
OM011008-PSE-FE series PoE switch is designed by OLYCOM for meeting the demand of PoE power supply.
It adopts the latest high-speed Ethernet switching chip and ultra-high backplane bandwidth design, with extremely fast data processing capability to improve smooth data transmission performance.
It has 8 Poe-powered RJ45 ports and 2 RJ45 uplink ports.
All of eight RJ45 ports support IEEE 802.3af/at standard, with a maximum power supply of 30W for a single port and 150W for the whole machine, which can automatically detect and identify the powered devices that comply with IEEE 802.3af/at standard and supply power for the priority mechanism through the network cable.
|
Power
|
Power Adapter Voltage
|
|
AC 110V-240V
|
|
|
|
Consumption
|
|
120W/150W
|
|
|
Network Connector |
Network Port
|
PoE Ethernet Port
|
1~8 Port : 10/ 100Mbps
|
|
|
|
|
Ethernet port
|
Uplink Port : 10/ 100/1000Mbps
|
|
|
|
Fiber Port
|
|
Uplink Port : 1000M SFP
|
|
|
|
Transmission Distance
|
|
1~8 Port :
100Mbps:0~100m; 10Mbps: 0~250m; |
|
|
|
|
|
Uplink Port : 0 ~ 100m
|
|
|
|
|
|
SFP: depend on the SFP transceiver (20km-120km)
|
|
|
|
Transmission Medium
|
|
Cat5/5e/6 standard network cable
|
|
|
Network Switch |
Network Standard
|
|
IEEE802.3/802.3u,
IEEE802.3x, IEEE802.ab |
|
|
|
Switching Capacity
|
|
2.0Gbps
|
|
|
|
Packet Buffer Memory
|
|
1Mbits
|
|
|
|
Throughput
|
|
1.488Mpps
|
|
|
|
MAC Table
|
|
1K
|
|
|
|
Packet Forwarding rate
|
|
10Mbps:14880pps/port
100Mbps: 148800pps/port |
|
|
Power Over Ethernet
|
PoE Standard
|
|
IEEE 802.3af/at
|
|
|
|
PoE Power Supply
|
|
12 45 + ,36 78- , 8 core power supply
|
|
|
|
PoE Power
|
|
af=15.4W,at=30W for each port
|
|
|
RJ45 port
|
Port Function
|
|
Power priority mechanism,
fast and forward, MAC automatic learning and aging IEEE802.3X Full-duplex and mode and back-pressure for Half-duplex mode |
|
|
LED Indicator
|
LED Indicator
|
|
LINK/ACT.100Mbps;
PoE Status Indicator; Power indicator;Extender |
|
|
Environmental
|
Working temperature
|
|
0C~55C
|
|
|
|
Relative Humidity
|
|
20~95%
|
|
|
|
Storage temperature
|
|
-20C~70C
|
|
|
Mechanical
|
Dimension (L ×W × H)
|
|
220mm*140mm*45mm
|
|
|
|
Color
|
|
Black
|
|
|
|
Weight
|
|
1.05kg
|
|
