Since 2001, Topright Industrial Technology is engaged in the development, design, production and sales in one of the sales of industrial electric heating technology company, according to the customer needs, provide tailored solution of design, committed to the electric heating and temperature measurement in the field of development more than 15 years, constantly pursuit of technological value-added products,promote industry technology progress, Topright products have been exported to Europe, the americas, Asia, etc. More than 200 countries.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Topright
-
Dimension(L*W*H):
-
125x1740x1.5mm
-
Weight:
-
0.6
-
Working Temperature Range:
-
-5 - 250 ℃
-
Insulation material:
-
Silicon rubber
-
Heating wire:
-
Ni-Cr or FeCrAl
-
Color:
-
Red or special as the customer's demand
-
Lead wire:
-
300-1500mm
-
Thermocouple:
-
K or J type
-
Thermostat:
-
With or w/o
-
3M self-adhesive:
-
With or w/o
-
Can customized:
-
Yes
-
wattage:
-
0.5-0.7w/cm2
-
Certification:
-
CE ROHS
Quick Details
-
Type:
-
Air Heater
-
Power Source:
-
Electric
-
Voltage:
-
12-240v
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Topright
-
Dimension(L*W*H):
-
125x1740x1.5mm
-
Weight:
-
0.6
-
Working Temperature Range:
-
-5 - 250 ℃
-
Insulation material:
-
Silicon rubber
-
Heating wire:
-
Ni-Cr or FeCrAl
-
Color:
-
Red or special as the customer's demand
-
Lead wire:
-
300-1500mm
-
Thermocouple:
-
K or J type
-
Thermostat:
-
With or w/o
-
3M self-adhesive:
-
With or w/o
-
Can customized:
-
Yes
-
wattage:
-
0.5-0.7w/cm2
-
Certification:
-
CE ROHS
Product Description
Silicon Rubber Heater with 3M adhesive backing
Silicon rubber heater pad is made of silicone rubber and glass fiber cloth are compounded sheet, Silicone rubber heater has good flexibility, can be associated with an object to be heated is close contact; the heating elements of nickel alloy foil processing form, more uniform heating. In this way, we can let the heat transfer to any desired place.
Pordutc Feature
1.Maximum temperature resistant of insulant: 300°C
2.Maximum Operating Temperatures: 250 °C
3.Power deviation: 8%
4.insulating resistance: ≥ 5 MΩ
5.Compressive strength: 1500V/5
6.Width: 20mm-1000mm;Length: 25mm-1000mm
7. Fast heat diffusion, Uniform heat transfer, Directly heat objects on;high thermal efficiency, high strength, long service life,work safe uneasy for ageing.
Detailed Images
|
Volume
|
200Liter
|
20Liter
|
200Liter
|
200Liter
|
||||
|
OD(oil barrel)
|
580mm
|
300mm
|
580mm
|
580mm
|
||||
|
Size
|
250x1740mm
|
200x860mm
|
125x1740mm
|
150x1740mm
|
||||
|
Voltage & wattage
|
200v/2000w
|
200v/800w
|
200v/1000w
|
200v/1000w
|
||||
|
Adjusted Temperature
|
30-150 °C
|
30-150 °C
|
30-150 °C
|
30-150 °C
|
||||
|
Weight(kg)
|
1.4
|
0.6
|
0.8
|
0.9
|
||||
|
Waterproof
|
IP68
|
IP68
|
IP68
|
IP68
|
||||
|
Note: Any size is available in China Topright Industrial
|
|
|
|
|
||||
Related Products
Applications
Silicone rubber heater application
1.Silicone rubber band heater can be used in damp, no explosive gas atmosphere, industrial equipment pipelines, heat preservation for can and barrel.
2. Silicone rubber heater can be used as a frozen prevention, air conditioner compressor, assisting heating of electrical equipment3 medical devices ( such as blood analyzers, test tube heater, medical care, body slimming belt corset compensation such as heat )
3. Silicone rubber heater can be used as medical equipment and medical care (such as blood tube heater, blood analyzer, heat supplementary for corset and waistband
Production Flows
Certifications
Our Company
Topright Technology Culture
How does your factory do regarding quality control?
"
Quality is in my hand,customer in our heart
". Topright people always attach great importance to quality controlling from the very beginning to the very end.
Topright continuously strive to find ways of reducing our production costs, and passing the savings over to you.Superior quality, stylish designs, competitive price and perfect service won us honorable customers. Topright service includes regular and thorough inspections throughout the manufacturing process, eliminating the need to employ additional quality control inspectors.
