- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
MIRACLE/METERPRO
-
Model Number:
-
DTS-121D
-
Accuracy Class:
-
Class1 or class2
-
Output Voltage:
-
3x220/380
-
Operating Temperature:
-
-30 ~55℃
-
Dimensions:
-
125*88*73mm
-
Type:
-
IC card prepaid kwh meter
-
Frequency:
-
50/60Hz
-
Standard:
-
IEC62053-21,IEC62052-11,IEC62053-31,DIN43864
-
Communication:
-
extensiable RS485/Modbus-RTU/infrared
-
Package:
-
Foam box with master carton
-
Features:
-
programmable
-
Function:
-
Prepayment
-
Display:
-
8 digits LCD
-
OEM:
-
Allowed
-
Name:
-
electrical meter 3 phase
Quick Details
-
Phase:
-
Three Phase
-
Measuring Energy Range:
-
CT/5/5(30)/10(60)/20(80);30(100)
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
MIRACLE/METERPRO
-
Model Number:
-
DTS-121D
-
Accuracy Class:
-
Class1 or class2
-
Output Voltage:
-
3x220/380
-
Operating Temperature:
-
-30 ~55℃
-
Dimensions:
-
125*88*73mm
-
Type:
-
IC card prepaid kwh meter
-
Frequency:
-
50/60Hz
-
Standard:
-
IEC62053-21,IEC62052-11,IEC62053-31,DIN43864
-
Communication:
-
extensiable RS485/Modbus-RTU/infrared
-
Package:
-
Foam box with master carton
-
Features:
-
programmable
-
Function:
-
Prepayment
-
Display:
-
8 digits LCD
-
OEM:
-
Allowed
-
Name:
-
electrical meter 3 phase
Details
Product Paramenters
|
Reference voltage
|
3X57.5/100V, 3X220/380V ~400V.3X100V, 3X380V
|
|
Working voltage range
|
Provisional voltage range:90%Un~110%Un
Expending voltage range :80%Un~115%Un
|
|
Current
|
CT type: 3x1.5(6)A
Direct type:3x2.5(10)A,3X5(20)A,3X10(40)A, 3X15(60)A,3X20(80)A,3X30(100)A
|
|
Accuracy level
|
Active Class 1.0
Reactive class 2.0
|
|
Operating temperature
|
Regulated temperature :-25~+60c
Limit temperature:-40c~+70c
|
|
Relative humidity
|
≤95(no condensation
|
|
Frequency
|
(50±2.5)Hz/(60±2.5)Hz
|
|
Static power consumption
|
<1.5W, 10VA
|
