Quick Details
-
Certificate:
-
CE/FCC
-
Warranty:
-
12 Months
-
Output waveform:
-
Pure Sine wave/Same as input(Bypass mode)
-
Color:
-
Black
-
Application:
-
Home Appliance, outdoor
-
Rated power:
-
4000W
-
Protection:
-
Overload
-
Nominal Efficiency:
-
>88%(Peak)
-
Line Mode Efficiency:
-
>95%
Quick Details
-
Output Current:
-
Load
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
4000W DC to AC Power Inverter
-
Certificate:
-
CE/FCC
-
Warranty:
-
12 Months
-
Output waveform:
-
Pure Sine wave/Same as input(Bypass mode)
-
Color:
-
Black
-
Application:
-
Home Appliance, outdoor
-
Rated power:
-
4000W
-
Protection:
-
Overload
-
Nominal Efficiency:
-
>88%(Peak)
-
Line Mode Efficiency:
-
>95%
4000 Watt Pure Sine Wave RV Power Rechargeable Inverter
|
HC pure sine wave inverter is the latest model,developed on the base of our previous PSW 7 series, the HC charger has achieved significant improvements on battery charging, AC transfer, etc. By adopting DIP(dual in-line package) switch, and provides more smart options for users to customize the performance of the device. |
Product Description
Feature
1. High overload ability, up to 300% rated power(20 sec.).
2. adopts low quiescent current, and power saver mode to reduce power consumption
3. Uses PFC(power factor correction) for charger, less power consumption .
4. It has 15s delay before transfer when it resumes, and overload protection when inverter equips with generator.
5. 10ms typical transfer time between battery and AC, which guarantees power continuity of HC charger.
6. Allows start up and through power with depleted batteries.charge rate up to 90Amp
7. It can offer 3-step intelligent battery charging, and equipped with 8 preset battery type selector for totally flat batteries.
8. LCD status display, battery/AC priority switch, USB communication port.(Optional)
9. Auto voltage rugulation optional(HS)
9. Auto voltage rugulation optional(HS)
| Model(HC) | 1000W | 1500W | 2000W | 3000W | 4000W | 5000W | 6000W | |
|
Inverte
Output |
Continuous Output Power | 1000W | 1500W | 2000W | 3000W | 4000W | 5000W | 6000W |
| Surge Rating(20s) | 3000W | 4500W | 6000W | 9000W | 12000W | 15000W | 18000W | |
|
Cpable of Starting Electric
Motor |
1HP | 1.5HP | 2HP | 3HP | 4HP | 5HP | 6HP | |
| Output Waveform | pure sine wave/same as input(Bypass mode) | |||||||
| Nominal Efficiency | >88%(Peak) | |||||||
| Line Mode Efficiency | >95% | |||||||
| Power Factor | 0.9-1.0 | |||||||
|
Nominal Output
Voltage THD |
100-110-120Vac/220-230-240Vac
<10% |
|||||||
| DC Input | Nominal Input Voltage | 12.0Vdc 24Vdc,48Vdc | ||||||
| Minimum Start Voltage | 10.0Vdc | |||||||
|
Idle Consumption-Search
Mode |
< 25 W when Power Saver On | |||||||
| Charge | Input Voltage Range |
Wide:90~135Vac/164~243Vac;
Narraw:100-135Vac/194~243Vac; |
||||||
| Output Voltage | Depends on battery type | |||||||
| Max Charge Rate | 35A/70-90A Max (Charger Current Control) | |||||||
| Remote Control | Yes.Optional | |||||||
|
Bypass &
Protection |
Input Voltage Waveform | Sine Wave(Grid or Generator) | ||||||
| Nominal Voltage | 120Vac | 230Vac | ||||||
| Low Voltage Trip | 80V/90V±4% | 184V/154V±4% | ||||||
| High Voltage Trip | 140V±4% | 253V±4% | ||||||
| Max Input AC Voltage | 150VAC | 270VAC | ||||||
| Nominal Input Frequency | 50Hz or 60Hz(Auto detect) | |||||||
|
Mechanical
Specification |
Mounting | Wall mount | ||||||
|
Inverter
Dimensions(L*W*H) |
382*218*179mm | 442*218*179mm | 598*218*179mm | |||||
| Inverter Weight | 14KG | 16KG | 19KG | 24KG | 32KG | 34KG | 36KG | |
|
Shipping
Dimensions(L*W*H) |
520*315*300mm | 580*315*300mm | 740*315*300mm | |||||
| Shipping Weight | 16KG | 18KG | 21KG | 26KG | 35KG | 37KG | 39KG | |
| Display | Status LEDs/Status LEDs+LCD | |||||||
