Programmable supply priority for PV , battery or Grid
High PV input voltage range(55~450VDC)
Built-in Max 110A(3.6KW&6.2KW) MPPT solar charge
Compatibe with lithium-ion battery
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Inverter Efficiency:
-
98%
-
Place of Origin:
-
China
-
Model Number:
-
SP serial 2200-7000VA
-
Input Voltage:
-
230VDC
-
Output Voltage:
-
230VDC
-
Output Current:
-
15.7A
-
Output Frequency:
-
50/60Hz
-
Size:
-
405X286X98MM 423X290X100MM 423X310X120MM
-
Certificate:
-
iso
-
Warranty:
-
1 Year
-
Weight:
-
8KGS
-
OEM:
-
Support
-
Product Name:
-
Single Phase Hybrid Solar Inverter
-
Protection:
-
Overcharge Protection Support
-
Display:
-
LCD Monitor
-
Inverter type:
-
DC to AC
-
Keyword:
-
Single Phase Hybrid Solar Inverter
-
Color:
-
White
-
Efficiency:
-
98%
-
Rated AC output power:
-
1800W-6200W
-
Frequency:
-
50/60Hz
Quick Details
-
Output Power:
-
1.8KW
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
98%
-
Place of Origin:
-
China
-
Model Number:
-
SP serial 2200-7000VA
-
Input Voltage:
-
230VDC
-
Output Voltage:
-
230VDC
-
Output Current:
-
15.7A
-
Output Frequency:
-
50/60Hz
-
Size:
-
405X286X98MM 423X290X100MM 423X310X120MM
-
Certificate:
-
iso
-
Warranty:
-
1 Year
-
Weight:
-
8KGS
-
OEM:
-
Support
-
Product Name:
-
Single Phase Hybrid Solar Inverter
-
Protection:
-
Overcharge Protection Support
-
Display:
-
LCD Monitor
-
Inverter type:
-
DC to AC
-
Keyword:
-
Single Phase Hybrid Solar Inverter
-
Color:
-
White
-
Efficiency:
-
98%
-
Rated AC output power:
-
1800W-6200W
-
Frequency:
-
50/60Hz
Product Description
Advantage
Pure sine wave inverter
Programmable supply priority for PV , battery or Grid
High PV input voltage range(55~450VDC)
Built-in Max 110A(3.6KW&6.2KW) MPPT solar charge
Compatibe with lithium-ion battery
Programmable supply priority for PV , battery or Grid
High PV input voltage range(55~450VDC)
Built-in Max 110A(3.6KW&6.2KW) MPPT solar charge
Compatibe with lithium-ion battery
Title goes here.
Support BMS communication with Lithium battery
Smart battery charge design to optimize battery life
Overload,high temperature,inverter output short circuit protection
Cold start function
Intelligent fan speed adjustment
Built-in anti-dusk kit for harsh enviromen(optional)
WIFI&GPRS available for IOS and android
Smart battery charge design to optimize battery life
Overload,high temperature,inverter output short circuit protection
Cold start function
Intelligent fan speed adjustment
Built-in anti-dusk kit for harsh enviromen(optional)
WIFI&GPRS available for IOS and android
Related Products
Specification
|
MODEL
|
SP-2200
|
SP-3200
|
SP-4200
|
SP-7000
|
||||
|
Rated Power
|
2200VA/1800W
|
3200VA/3000W
|
4200VA/3800W
|
7000VA/6200W
|
||||
|
INPUT
|
|
|
|
|
||||
|
Voltage
|
230VAC
|
|
|
|
||||
|
Selectable Voltage Range
|
170-280VAC(for personal computers)
90-280VAC(for home appliances) |
|
|
|
||||
|
Frequency Range
|
50Hz/60Hz (Auto sensing)
|
|
|
|
||||
|
OUTPUT
|
|
|
|
|
||||
|
AC Voltage Regulation (Batt.Mode)
|
230VAC±5%
|
|
|
|
||||
|
Surge power
|
4400VA
|
6400VA
|
8000VA
|
14000VA
|
||||
|
Transfer Time
|
10ms (for personal computers)
20ms (for home appliances) |
|
|
|
||||
|
Wave form
|
Pure Sine Wave
|
|
|
|
||||
|
BATTERY & AC CHARGER
|
|
|
|
|
||||
|
Battery Voltage
|
12VDC
|
24VDC
|
24VDC
|
48VDC
|
||||
|
Floating Charge Voltage
|
13.5VDC
|
27VDC
|
27VDC
|
54VDC
|
||||
|
Overcharge Protection
|
15.5VDC
|
31VDC
|
31VDC
|
61VDC
|
||||
|
Maximum charge current
|
60A
|
|
80A
|
|
||||
|
SOLAR CHARGER
|
|
|
|
|
||||
|
MAX.PV Array Power
|
2000W
|
3000W
|
5000W
|
6000W
|
||||
|
MPPT Range@ Operating Voltage
|
55-450VDC
|
|
|
|
||||
|
Maximum PV Array Open Circuit Voltage
|
450VDC
|
|
|
|
||||
|
Maximum Charging Current
|
80A
|
|
110A
|
|
||||
|
Maximum Efficiency
|
98%
|
|
|
|
||||
|
PHYSICAL
|
|
|
|
|
||||
|
Dimension.D*W*H(mm)
|
405*286*98mm
|
|
423*290*100mm
|
423*310*120mm
|
||||
|
Net Weight (kgs)
|
4.5kg
|
5.0kg
|
7.0kg
|
8.0kg
|
||||
|
Communication Interface
|
RS232/RS485(Standard)
GPRS/WIFI(Optional) |
|
|
|
||||
|
OPERATING ENVIRONMENT
|
|
|
|
|
||||
|
Humidity
|
5% to 95% Relative Humidity(No-condensing)
|
|
|
|
||||
|
Operating Temperature
|
-10℃ to 55℃
|
|
|
|
||||
|
Storage Temperature
|
-15℃ to 60℃
|
|
|
|
||||
