This machine is designed for metal products cutting. Stainless steel, cold rolled steel, carbon steel, galvanized steel, aluminum, copper, iron and so on all kinds of metal
- Product Details
- {{item.text}}
Quick Details
-
Control System Brand:
-
ZONTO
-
Cutting Area:
-
600x900/1000x800/1200x600/1300x900/1600x1000
-
Cutting Thickness:
-
Depends on Materials
-
Control Software:
-
ZONTO
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
ZONTO
-
Weight (KG):
-
50 KG
-
Core Components:
-
Laser device
-
Power Supply:
-
AC220-240V, 50/60Hz
-
Power Consumption:
-
1250W
-
Machine Weight:
-
260KG/430KG/525KG/605KG
-
Working Environment:
-
Temperature: 5℃~40℃ Humidity: 5%~80% No condensate & no dust or dirt
-
Laser Power:
-
60W-130W
-
Engraving Speed:
-
0-1500mm/s
-
Working Area:
-
600*900mm Optional
-
Certification:
-
ce
Quick Details
-
Laser Type:
-
CO2
-
Cutting Speed:
-
0-150mm/s
-
Cooling Mode:
-
WATER COOLING
-
Control System Brand:
-
ZONTO
-
Cutting Area:
-
600x900/1000x800/1200x600/1300x900/1600x1000
-
Cutting Thickness:
-
Depends on Materials
-
Control Software:
-
ZONTO
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
ZONTO
-
Weight (KG):
-
50 KG
-
Core Components:
-
Laser device
-
Power Supply:
-
AC220-240V, 50/60Hz
-
Power Consumption:
-
1250W
-
Machine Weight:
-
260KG/430KG/525KG/605KG
-
Working Environment:
-
Temperature: 5℃~40℃ Humidity: 5%~80% No condensate & no dust or dirt
-
Laser Power:
-
60W-130W
-
Engraving Speed:
-
0-1500mm/s
-
Working Area:
-
600*900mm Optional
-
Certification:
-
ce
Applicable industries: Advertisement, arts and crafts, leather, toys, garments, model , building upholster, computerized embroidery and clipping, jeans, packaging and paper industry.
|
Model
|
ZT-CC0604/1080/1206/1309/1610
|
|
Engraving Area(mm)
|
600*400 / 1000*800 / 1200*600 / 1300*900 / 1600*1000
|
|
Overall Dimensions(mm)
|
1530*1070*1070/1825*580*1200/1910*1380*1100/1910*1710 *1370/2240*1780*1290
|
|
Machine Weight(KG)
|
260 / 430 / 430 / 525 / 605
|
|
Control System
|
Ruida system
|
|
Laser Power
|
60-130W
|
|
Cooling Way
|
Water chiller
|
|
Engraving Speed(m/min)
|
0~2000mm/min
|
|
Power Requirements
|
AC 220-240V,50/60Hz
|
|
Environmental Requirements
|
Temperature: 5 ~ 40 ℃ Humidity: 5 ~ 80%, no condensate, no dust or dirt.
|
Main part devices:
Laser Tube Power---
CO2 Glass tube
High efficiency tube with stable laser path, it ensures the cutting performance steady.
Engraving area
We provide different sizes cutting beds according to your cutting material sizes.
Belt
Belt is from Taiwan, let the working process smoothly.
LCD digital control panel
Embedded with China top brand Ruida
control system, system language contains English, will be easier to operate.
Servo motors and drivers
Brand Delta, it is a popular brand. It ensures the cutting and engraving speed steady and fast.
Imported linear guide
Ensuring the stable operation and high-precision.
Application areas:
Log wooden board cutting
Wooden thin board engraving and cutting
Dried coconut cutting and engraving
Acrylic cutting
Leather cutting and engraving
Bamboo chopping board engraving
Wine barrel brand name engraving
Paper engraving
Jeans cloth marking engraving
Cutting material thickness reference list:
|
Cutting material
|
Laser power 80W
|
Laser power 100W
|
Laser power 130W
|
Laser power 150W
|
|
Acrylic
|
15mm
|
18mm
|
20mm
|
25mm
|
|
Medium density fiberboard
|
5mm
|
6mm
|
8mm
|
10mm
|
|
Wood
|
12mm
|
15mm
|
18mm
|
18mm
|
|
Rubber
|
4mm
|
5mm
|
6mm
|
7mm
|
|
Leather
|
6mm
|
7mm
|
8mm
|
10mm
|
|
Cloth
|
6mm
|
7mm
|
8mm
|
10mm
|
|
Paper
|
7mm
|
8mm
|
8mm
|
10mm
|
Hot Product
Laser welding machine
Welding in thin stainless steel plate, iron plate, aluminum plate and other metal materials. It can perfectly replace the traditional argon arc welding and electric welding technology.
Why choose us
Because we need you!!! Of course.
With over 15 years experience, Zonto Laser has established a complete system for the development and manufacture of coding, marking, printing and welding technologies, as well as its worldwide aftermarket products and customer service.
Globally-proven, flexible and high quality product printing systems for a diverse range of applications. Our coding, marking and printing solutions are versatile, easy to integrate, easy to operate - the perfect fit on many printing applications and substrates. With the latest networking technology, the laser technology and the producing graphic code quality, our machines are ideal not only for batch and date coding but also for complex code formats, logos, QR code, and barcode. If you are looking for a coding, printing and marking solution you could always find one in our products.
Award-winning product printing solutions backed by years of trust and expertise; our heritage in product coding means compliance and peace of mind.
Successful Project
Malaysia cocoman company
In July, 2019, we attended a food packing and labelling exhibition in PUTRA World Trade center, our client told us that in he needed machine to cut the dried coconut shell to make all kinds of souvenirs, like coconut bowls, earrings, spoons and so on. After we talked in our booth, he purchased our laser cutting machine for his dried coconut shells.
Project in Malaysia
（Coconut marking）
Project in Zhejiang
(Wooden board engraving)
Project in Zhejiang province, China
(Wooden car accessories )
Project in Australia
(Wine barrel brand name marking)
Project in Cambodia
(Wooden cutting board)
Project in Jilin
(Big size wood board cutting)
Project in Indonesia
Project in Cambodia
(PET bottle Water line)
Project in Thailand
(Wooden spoon marking)
