Quick Details
-
Positioning Accuracy (mm):
-
0.01 mm
-
Number of Axes:
-
Single
-
Travel (X Axis)(mm):
-
600 mm
-
Travel (Y Axis)(mm):
-
900 mm
-
Repeatability (X/Y/Z) (mm):
-
0.02 mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Hopetool
-
Voltage:
-
AC220V
-
Dimension(L*W*H):
-
600*900*200mm
-
Weight (KG):
-
220
-
lathe table:
-
Aluminium + PVC
-
drive system Z axis:
-
Ball screw
-
Running environment:
-
Temperature:0-45℃
-
XYZ travel positioning accuracy:
-
±0.01mm
-
Interface:
-
USB or parallel port
-
Max working speed:
-
25m/min
-
Command language:
-
G code
-
Software environment:
-
Wentai type3 artcam
-
Power(W):
-
2.2KW
Quick Details
-
Working Table Size(mm):
-
600x900
-
Machine Type:
-
CNC Router
-
Range of Spindle Speed(r.p.m):
-
0 - 24000 rpm
-
Positioning Accuracy (mm):
-
0.01 mm
-
Number of Axes:
-
Single
-
Travel (X Axis)(mm):
-
600 mm
-
Travel (Y Axis)(mm):
-
900 mm
-
Repeatability (X/Y/Z) (mm):
-
0.02 mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Hopetool
-
Voltage:
-
AC220V
-
Dimension(L*W*H):
-
600*900*200mm
-
Weight (KG):
-
220
-
lathe table:
-
Aluminium + PVC
-
drive system Z axis:
-
Ball screw
-
Running environment:
-
Temperature:0-45℃
-
XYZ travel positioning accuracy:
-
±0.01mm
-
Interface:
-
USB or parallel port
-
Max working speed:
-
25m/min
-
Command language:
-
G code
-
Software environment:
-
Wentai type3 artcam
-
Power(W):
-
2.2KW
Products Description
3D Router CNC 600*900 / Small CNC Milling Machine / Mini ATC CNC Router 6090
Characteristic
1.This machine is simple CNC router with automatic tools change 4 or 6 pcs tools.
2.imported linear rail,self lubricating glide.
3.our routers have the features of recarving after stop and the power failure may be restored.
4.unique preservation way of the zero point.
5.use for long time and no distortion.
6.this type is suitable for advertisement,wood engraving.
2.imported linear rail,self lubricating glide.
3.our routers have the features of recarving after stop and the power failure may be restored.
4.unique preservation way of the zero point.
5.use for long time and no distortion.
6.this type is suitable for advertisement,wood engraving.
Performance Parameter
|
number
|
Description
|
parameter
|
|
1
|
XYZ working area
|
600*900*200mm
|
|
2
|
Table size
|
740*1400mm
|
|
3
|
XYZ travel positioning accuracy
|
±0.01mm
|
|
4
|
XYZ repositioning positioning accury
|
±0.01mm
|
|
5
|
Gantry
|
Steel tube
|
|
6
|
lathe structure
|
tube structure
|
|
7
|
drive system X-Y axis
|
Ball screw
|
|
8
|
drive system Z axis
|
Ball screw
|
|
9
|
Spindle power
|
2.2KW
|
|
10
|
Max velocity
|
25m/min
|
|
11
|
Max working speed
|
15m/min
|
|
12
|
Spindle speed
|
0-24000rmp
|
|
13
|
work mode
|
Hybrid servo motor
|
|
14
|
Working voltage
|
AC220V/380V
|
|
15
|
Command language
|
G code
|
|
16
|
Interface
|
USB
|
|
17
|
Operating system
|
DSP/Mach3/Ncstudio
|
|
18
|
Flash memory
|
128
|
|
19
|
X-Y resolution
|
0.025mm
|
|
20
|
Software environment
|
Wentai type3 artcam
|
|
21
|
Running environment
|
Temperature:0-45°C
|
|
22
|
Packing size
|
1900*1200*1800mm
|
|
23
|
Net weight
|
400kg
|
|
24
|
Gross weight
|
500kg
|
Application :
1. Wood furniture industry Wave plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.
2. Advertising industry Signage; Logo; Badges; Display board; Meeting signboard; Billboard. Advertising filed, sign making, acrylic engraving and cutting, crystal word making, blaster molding, and other
advertising materials derivatives making.
advertising materials derivatives making.
3. Die industry A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand , plastic sheeting, PVC pipe, and other non-metallic mold.
4. Artwork and Decoration wood crafts; gift box; jewelry box.
5. Others Relief sculpture and 3D engraving and Cylindrical object.
