Quick Details
-
Model Number:
-
2061
-
Package:
-
Wooden pallet Package
Quick Details
-
Purity:
-
99.9%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XZD
-
Model Number:
-
2061
-
Package:
-
Wooden pallet Package
3005 Copper Polishing Agent
Scope of application and characteristics
1. This is a polishing specially for thick copper workpiece of electroplating.
2. The brightness of polishing is high, and it can replace acid copper and save cost greatly.
3. The working solution is stable, and the operation process is simple, easy to control, and can be used for many times.
4. P olishing solution for copper layer corrosion less, it solves the traditional hydrogen peroxide polishing on the copper layer corrosion, easy to cause the workpiece has internal stress burst and other problems.
Operating condition
|
Process and Conditions |
Standard Range |
Optimal Value |
|
3005 Copper Polishing Agent |
80%-90% |
85% |
|
Sulfuric A cid |
10%-20% |
15% |
|
Temperature |
Normal T emperature |
|
|
Time |
5-30s |
|
|
PH |
Extremely A cidic |
|
Process Flow :
Degreasing → Washing → Activation → Washing → Plating thick red copper → Washing → Polishing → Washing →
501 anti-discoloration agent closed (3%-5%) → pure water cleaning (depending on the appearance needs) → drying
Note: 501 anti-discoloration agent closed to open the tank with pure water, in order to ensure the anti-discoloration effect, it is best not to use water to wash.
Process requirements
1. Polishing tank material ----- PVC, or acid and alkali corrosion resistant chemical special plastic.
2. Hanging tool or hanging blue ----- acid and alkali corrosion resistant chemical special plastic, titanium, 316 stainless steel.
Consumption supplement
1. Each liter of polishing working fluid can polish 5-10 kg workpiece.
2. After using for a period of time, polishing water color will gradually turn from red-brown to dark green, polishing ability gradually weakened, can be supplemented with 10-20% red copper polishing agent working fluid, if repeatedly consume added to achieve the polishing consequences, we must re-open the tank.
Precautions
1. Our series products do not contain cyanide and can be used as general chemicals.
2. The plating solution is alkaline, so it is absolutely not allowed to add strong acids such as sulfuric acid directly. If the PH needs to be lowered, acetic acid can be added, but it is recommended to operate during downtime.
Maintenance
Prohibit take alkaline substances into the polishing tank, and try to avoid excessive water being brought in to maintain the service life of the polishing solution.
Package: Fiber bag, Plastic bucket, Cardboard bucket, Carton etc, according to client's request and the
product product features
Shiping by: air, sea, subway, road.
