- Product Details
- {{item.text}}
Quick Details
-
Product name:
-
Walking Tractor
-
Model:
-
354,404,504
-
After-sales Service Provided:
-
Free spare parts
-
contact sales:
-
Nancy +8618505419920
Quick Details
-
Brand Name:
-
SAMTRA
-
Place of Origin:
-
Shandong, China
-
Weight:
-
900 KG
-
Product name:
-
Walking Tractor
-
Model:
-
354,404,504
-
After-sales Service Provided:
-
Free spare parts
-
contact sales:
-
Nancy +8618505419920
MORE PICTURES
Specification
|
tractor model |
YTO-MF504C |
|
TYPE |
4*4 |
|
DIEMENSION |
3740mm*(1615-1815)mm*2440mm |
|
Axle base |
1970mm |
|
Min ground clearance |
350mm |
|
Min operable mass |
2270kg |
|
Wheel tread(front/rear) |
1275mm/1300mm-1500mm |
|
Tire size |
8.3-20/12.4-28 |
|
Steering device |
hydraulic |
|
brake |
Dry,disc-tyre,machinery operation |
|
Hydraulic output |
2 pairs |
|
Connective equipment for trailer |
Swing drawbar |
|
Safety standard |
yes |
|
Diesel engine model |
A498BT1 |
|
TYPE |
4-cylinder,vertical,water-cooled,4 stroke,direct injection,pre-heater |
|
displacement |
3.168L |
|
Power and rated speed |
36.8kw/2400r/min |
|
Max torque/rated speed |
>186n.m/1600-1800 r/min |
|
Cylinder bore/stroke |
98mm*105mm |
|
Gear box |
|
|
Gears(forward/reverse) |
8/8 side shift control |
|
speed(forward/reverse) |
2.65-28.80/2.24-24.68 |
|
Pto power |
32.5 kw |
|
Rated pto revolution speed |
540 /1000 r/min(6 keys) |
|
clutch |
10 inch,dry,double-acting |
|
Kind of three point suspension |
Rear three pointsuspension, categoryⅠ |
|
Control model of tilling depth |
Force and position adjustment |
|
Lifting force |
8.28kn |
