Quick Details
-
Voltage:
-
380v
-
Power:
-
5kw
-
Dimension(L*W*H):
-
1800*1200*1700mm
-
Weight:
-
800kg
-
Name:
-
Automatic Paper Plate making machine
-
Finished Products:
-
paper plate/ paper dish
-
Raw material:
-
PE Coated Paper
-
Application:
-
Paper Industry
-
Function:
-
Embossing Folding Counting Cutting
-
paper plate size:
-
4-11inch(mould customized)
-
paper plate shape:
-
round ,square,leaf, love shape
-
Paper Materials:
-
Base paper, whicteboard paper, etc
-
Paper weight:
-
160-1000g/㎡
-
feature:
-
high capacity , easy operation
-
After Warranty Service:
-
Video technical support, Online support, Spare parts
-
Local Service Location:
-
None
-
Certification:
-
CE
-
After-sales Service Provided:
-
Free spare parts, Video technical support, Online support
Quick Details
-
Production Capacity:
-
50-80pcs/min
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Joconn
-
Voltage:
-
380v
-
Power:
-
5kw
-
Dimension(L*W*H):
-
1800*1200*1700mm
-
Weight:
-
800kg
-
Name:
-
Automatic Paper Plate making machine
-
Finished Products:
-
paper plate/ paper dish
-
Raw material:
-
PE Coated Paper
-
Application:
-
Paper Industry
-
Function:
-
Embossing Folding Counting Cutting
-
paper plate size:
-
4-11inch(mould customized)
-
paper plate shape:
-
round ,square,leaf, love shape
-
Paper Materials:
-
Base paper, whicteboard paper, etc
-
Paper weight:
-
160-1000g/㎡
-
feature:
-
high capacity , easy operation
-
After Warranty Service:
-
Video technical support, Online support, Spare parts
-
Local Service Location:
-
None
-
Certification:
-
CE
-
After-sales Service Provided:
-
Free spare parts, Video technical support, Online support
Biodegradable Paper Pulp Plate Molding machine/ named Paper dish making machine/ High Speed Paper Plate Making Machine Price
1.Introduction of Paper Pulp Plate Molding machine
This automatic high-speed paper pulp plate molding machine adopts the combination of mechanical and pneumatic working method, which has the advantages of faster output speed and higher safety performance. It has the functions of full-automatic pneumatic paper feeding, heat forming, automatic dish-out, constant temperature control and automatic counting.
With advantages of Fast production speed, safe operation and easy maintenance, t his automatic high-speed paper plate making machine is widely used to make various types of round paper plates, square paper plates, leaf or love shape paper dishes,etc.
2. Features of Paper Pulp Plate Molding machine
1. high quality:adopting high-efficiency booster cylinders, maximum pressure up to 5T
2. more convenient: more user-friendly design, more environmentally friendly working
3. wide application: mould shape and size can be customized, widely used in the production of paper or aluminum foil plates.
4. comeswith two working stations, can produce of different sizes and shapes paper plates at the same time.
3. Parameters of Paper Pulp Plate Molding machine
|
Model |
JC-ZD400 |
JC-ZD700 |
|
Capacity |
50-75pcs/min |
55-85pcs/min |
|
Function |
P aper plate Embossing Folding forming |
P aper plate Embossing Folding forming Counting |
|
Paper Grams |
160-1000g/m2 |
|
|
Paper Materials |
Base paper, whicteboard paper, white cardboard, aluminum foil paper or others |
|
|
Paper Plate Size |
4-11 inch(customized) |
|
|
Total Power |
3kw |
5kw |
|
800kg |
400kg |
700kg |
|
Specifications |
1800*1200*1700mm |
3850 * 850 * 1300 mm |
|
Air Supply |
0.5Mpa, 0.5cube/min |
0.4Mpa, 0.2cube/min |
4. Pictures of Paper Pulp Plate Molding machine
5. Final products
