Quick Details
-
Engine Brand:
-
LAIDONG
-
Weight:
-
1880 KG
-
Use:
-
Farm Tractor
-
Gearbox:
-
8F+2R shift or 8F+8R shuttle shift
-
Application:
-
Mini Farm Tractor
-
Keywords:
-
Farm Tractors 4wd
-
Color:
-
Customerized
-
Packaging Details:
-
Fixed in container
Quick Details
-
Brand Name:
-
STRONG
-
Place of Origin:
-
Guangdong, China
-
Marketing Type:
-
Hot Product 2024
-
Engine Brand:
-
LAIDONG
-
Weight:
-
1880 KG
-
Use:
-
Farm Tractor
-
Gearbox:
-
8F+2R shift or 8F+8R shuttle shift
-
Application:
-
Mini Farm Tractor
-
Keywords:
-
Farm Tractors 4wd
-
Color:
-
Customerized
-
Packaging Details:
-
Fixed in container
Product Description
Product Details
Product Paramenters
|
Model
|
|
TK254
|
TK304
|
TK354
|
TK404
|
TK454
|
|||||
|
Type
|
|
4x4
|
|
|
|
|
|||||
|
PTO power (KN)
|
|
15.6
|
18.79
|
21.9
|
24.5
|
28.2
|
|||||
|
Rated Traction( KN)
|
|
5.6
|
5.9
|
6.2
|
6.5
|
7
|
|||||
|
Dimensions(mm)
|
|
2850×1280×1400
|
2850×1280×1400
|
2850×1280×1400
|
3220×1500×2130
|
2850×1280×1400
|
|||||
|
Wheelbase（mm）
|
|
1715
|
1715
|
1820
|
2850×1280×14001820
|
1820
|
|||||
|
Front and rear track (mm)
|
|
960/1220
|
|
|
|
|
|||||
|
Rear track (mm)
|
|
960/1160/1200/1300
|
|
|
|
|
|||||
|
Minimum ground clearance(mm)
|
|
330
|
|
|
|
|
|||||
|
Turning circle radius(m)
|
|
3
|
|
|
|
|
|||||
|
Weight (KG)
|
|
1400
|
1418
|
1432
|
1450
|
1500
|
|||||
|
Clutch
|
|
Single stage clutch
|
|
|
|
|
|||||
|
Gearbox
|
|
8+2 shift
|
|
|
|
|
|||||
|
Front tire
|
|
6.00-12
|
|
|
|
|
|||||
|
Rear tire
|
|
9.6-16
|
|
|
|
|
|||||
|
Maximum lifting force at 610mm(KN)
|
|
4.13
|
4.96
|
5.79
|
6.64
|
7.5
|
|||||
|
Suspension mechanism
|
|
Three-point suspension cat I
|
|
|
|
|
|||||
|
Hydraulic output
|
|
Optional 1 or 2 groups
|
|
|
|
|
|||||
|
PTO speed r/min
|
|
540/760 or 540/1000 or 760/1000
|
|
|
|
|
|||||
|
PTO type
|
|
6-Ø35 Rectangular Spline
|
|
|
|
|
|||||
|
Engine brand
|
|
Xichai/Laidong/YTO
|
|
|
|
|
|||||
|
Engine type
|
|
Diesel engine
|
|
|
|
|
|||||
|
Engine cylinder
|
|
3
|
|
4
|
|
|
|||||
|
Start method
|
|
Electric
|
|
|
|
|
|||||
|
Radiater
|
|
10
|
|
|
|
|
|||||
|
Fuel tank
|
|
30
|
|
|
|
|
|||||
|
Engine oil pan(L)
|
|
5
|
|
|
|
|
|||||
|
Driveline oil (L)
|
|
20
|
|
|
|
|
|||||
|
Lifter(L)
|
|
9.5
|
|
|
|
|
|||||
Packing & Delivery
Packing:
Machine packing inside is plastic films and outside is fumigation wooden case.
Our wooden case is very strong,it can bear long time shipping on the sea.
And machine with preservative film, it can stop the salt sea water enter into the machine and make the machine corrosion.
Delivery:
For machines are big and heavy parcel, and different country with different delivery cost,so we suggest below delivery solution:
1. Over 1CBM or 100KG, we suggest send by Sea.
2. Below 1CBM or 100KG, we suggest send by Air.
3. Below 0.5CBM or 50KG, we suggest send by Express.
The price show on our website just the machine EXW price, please contact us for confirm delivery cost before you place order.
