Quick Details
-
Brand Name:
-
Jueli
-
Fork Length:
-
1150mm
-
Fork Width:
-
550/680mm
-
Weight (KG):
-
600 kg
-
Pallet Stacker:
-
1ton
Quick Details
-
Min. Lifting Height:
-
90 mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Jueli
-
Fork Length:
-
1150mm
-
Fork Width:
-
550/680mm
-
Weight (KG):
-
600 kg
-
Pallet Stacker:
-
1ton
Product Overview
PRODUCT SPECIFICATIONS
|
Project
|
Unit
|
Content
|
|
Model
|
|
CDDP
|
|
Rated load
|
kg
|
1000/1500/2000
|
|
Load center distance
|
mm
|
500
|
|
Driving wheel size
|
mm
|
φ210*70
|
|
Balance wheel size
|
mm
|
φ115*55
|
|
Fork lifting height
|
mm
|
1600/2000/2500/3000
|
|
Fork height when lowered
|
mm
|
90
|
|
The fork is wide outside
|
mm
|
550/680
|
|
After lifting, the height of the gantry
|
mm
|
2080/2580/3080/3580
|
|
Vehicle length
|
mm
|
1780
|
|
Full vehicle width
|
mm
|
800
|
|
Body height when gantry is lowered
|
mm
|
2080/1580/1830/2080
|
|
Minimum turning radius
|
mm
|
1500
|
|
Channel width, with 1000*1200 trays
|
mm
|
2537
|
|
Channel width, with 800*1200 trays
|
mm
|
2468
|
|
Travel speed, full/empty
|
km/h
|
4.2/5.6
|
|
Lifting speed, full load/no load
|
mm/s
|
80/100
|
|
Rate of descent, full/empty
|
mm/s
|
150/120
|
|
Maximum climbing capacity, full/no load
|
%
|
3/10
|
|
Lifting machine
|
kw
|
2.2
|
|
Battery voltage/rated capacity
|
V/Ah
|
2x12/80
|
FAQ
Q1:What can you buy from us? A2:Scissor Lift,Scissor type lifting platform, self-propelled lifting platform, self-propelled
lifting platform, lifting table,Forklifts, pallet trucks, electric forklifts, diesel forklifts, boarding bridges, lifting
equipment, etc. we can do it with one-stop service and one-stop procurement!
Q2: Can provide customized products? OEM products or ODM products? A2: Yes, can provide customized products according to your
requirement. Both OEM and ODM are acceptable. We do a lot of non-standard products, welcome your special custom-made.
Q3: What's the specification of the chargers?
A3: have all kinds of the chargers and welcome the customers to custom-made.
Q4: How about the delivery time? A4: Usually Ruyi producing time is 15-20 working days after we receive the advanced payment. For
some standard products, we have most in stock and could delivery immediately.
Q5: Can we print the LOGO on products? A5: Yes, the OEM is available with the permission of our customers.
Q6: What is your payment term? A6: T/T or L/C, if you want any other way, please contact us.
